Help CenterPHR-8-4 Digital Rockwell Hardness Tester,Brinell & Rockwell Hardness Tester,C Clamp Portable Rockwell Hardness Tester
Related Products
-
Digital Rockwell Hardness Tester,Brinell & Rockwell Hardness Tester,PHR-8-10NegotiableMOQ: 1 Piece -
Digital Rockwell Hardness Tester,portable Brinell Hardness Tester,C Clamp Portable Rockwell Hardness TesterNegotiableMOQ: 1 Piece
-
Digital Rockwell Hardness Tester,Chain Clamp Portable Rockwell Hardness Tester,C Clamp Portable Rockwell Hardness TesterNegotiableMOQ: 1 Piece
-
Portable Brinell Hardness Tester,Chain Clamp Portable Rockwell Hardness Tester,Portable Superficial Rockwell Hardness TesterNegotiableMOQ: 1 Piece
-
Portable Brinell Hardness Tester,Chain Clamp Portable Rockwell Hardness Tester,Portable Superficial Rockwell Hardness TesterNegotiableMOQ: 1 Piece
Specifications
Magnetic Type Rockwell Hardness Tester,rockwell hardness tester,Webster Hardness Tester for Aluminum Alloy,hardness testerhardPHC Clamp Portable Rockwell Hardness Tester
Introduction
Can accurately test large and medium size workpieces on site.
The testing principle and accuracy meet the requirements of
ISO 6508 and ASTM E110, tested by National Institute of
Metrology and the error is within 1.5HRC, same as the bench
type.
First clamp the workpiece, then apply the test force, stable
testing with high repeatability and precision.
Used for large and medium size moulds, shafts, rollers, tubing
and all kinds of metal parts.
Used for production inspection and acceptance inspection,
replacing Leeb hardness testers with lower precision.
Traceable standard hardness block.
Indenter inspected with standard Rockwell hardness tester.
Test force calibrated with load cells directly traceable to China
national secondary
Main Technical Parameters
Initial Test Force: 10kg
Total Test Force: 60kg, 100kg, 150kg
Force Applying Method: By screw
Indenter: 120°diamond cone
1.588mm carbide ball
Accuracy: Meets the requirements of ISO6508
Resolution: 0.5HR
Testing Range: HRA, HRB, HRC… HRV, etc. 15 scales.
Application: All metals, including steel, iron, copper,
aluminum,nickel,titanium, carburized
steel,carbide alloy, etc.
Application
Large hardness tester is very stable with fine repeatability, but the operation is not as simple as small ones.
Large hardness tester can be applied to large and medium sizeparts. When the workpiece is not suitable for the magnetic hardness tester, the best way is to test with large hardness testers.
The large hardness tester is recommended to test the workpieces that can be tested by the small testers with 4 inches opening size.
Standard Package
Tester
120°diamond cone indenter
1.588mm carbide ball indenter
3 Rockwell test blocks
Flat anvil
V anvil
Carrying case
Optional Accessories
120°diamond cone indenter
1.588mm, 3.175mm carbide ball indenter
6.35mm, 12.7mm steel ball indenter
Rockwell test blocks (HRA, HRC-High, HRC-Medium, HRC-Low,
HRB)
Model |
Speciment Size |
Net Weight |
Gross Weight |
Package Dimensions (mm x mm x mm) |
Remarks |
PHR-4-3 |
100×75 |
2.2~2.5 |
510×375×177 |
The first number in the model specification means the biggest opening width (inch), the second number means the biggest opening depth (inch). |
|
PHR-8-4 |
200×100 |
4.0 |
10.7 |
710×470×200 |
|
PHR-8-10 |
200×250 |
5.5 |
14.2 |
720×650×230 |
|
PHR-20-12 |
500×300 |
7.8 |
21.0 |
1020×760×240 |
