ANL-WP Series Cap Torque Gauge(1-20N.m), Bottle Cap Torque Meter, Bottle Torque Gauge, Bottle Lid Torque Tester

ANL-WP Series Cap Torque Gauge(1-20N.m), Bottle Cap Torque Meter, Bottle Torque Gauge, Bottle Lid Torque Tester thumbnail-1
ANL-WP Series Cap Torque Gauge(1-20N.m), Bottle Cap Torque Meter, Bottle Torque Gauge, Bottle Lid Torque Tester photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Graigar
Model Number:
ANL-WP
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Graigar
Model Number ANL-WP

Specifications

digital torque tester, bottle lid torque wrench, bottle cap torque meter







ANL-WP Series Cap Torque Gauge(1-20N.m), bottle cap torque meter, bottle torque gauge, bottle lid torque testerANL-WP Series Cap Torque Gauge(1-20N.m), bottle cap torque meter, bottle torque gauge, bottle lid torque testerANL-WP Series Cap Torque Gauge(1-20N.m), bottle cap torque meter, bottle torque gauge, bottle lid torque testerANL-WP Series Cap Torque Gauge(1-20N.m), bottle cap torque meter, bottle torque gauge, bottle lid torque testerANL-WP Series Cap Torque Gauge(1-20N.m), bottle cap torque meter, bottle torque gauge, bottle lid torque tester

Function:







Digital bottle lid torque meter is an intelligent multi-functional measuring instrument which is designed for testing various kinds of bottle lid torque. It main used in testing and calibrating tighten force, parts torsional destructive testing, etc. With features of simple operation, high precision, easy to carry, complete functions etc. It’s widely used in various kinds of electric, light industry, machinery manufacturing, research institutions, etc.







Specifications:

Type

Index
With printer
ANL-P1
ANL-P2
ANL-P3
ANL-P5
ANL-P10
ANL-P20
No printer
ANL-WP1
ANL-WP2
ANL-WP3
ANL-WP5
ANL-WP10
ANL-WP20
Measuring range / Division value
N·m
1.0000/0.0001
2.0000/0.0001
3.0000/
0.0001
5.0000/
0.0001
10.000/
0.001
20.000/
0.001
Kg·cm
10.200/
0.001
20.400/
0.001
30.600/
0.001
51.000/
0.001
102.00/
0.01
204.00/
0.01
Ib·in
8.850/
0.001
17.700/
0.001
26.550/
0.001
44.250/
0.001
88.50/
0.01
177.00/
0.01
Precision
±0.5%
Peak Value Sampling Frequency
2000HZ
Power
8.4V  1.2VX7 Ni-MH Battery group
Charging Time
4~6 Hours
Continuous using time of battery
About 10 Hours
Battery life
≥300 times
Size
400mm×200mm×200mm
Net Weight
12KG
Power adapter
Input:AC 220V 50HZ   Output:DC 10V 300mA



         Main features

1.         High precision, high resolution, quick sampling speed, full-screen display.
2.         Adopting high precision torque sensor, with torque direction display.
3.         Upper and lower limit value setting, red and green indicating lights and buzzer audible and visual alarm.
4.         Three units can be switched each other (N·m,kgf·cm,Ib·in).
5.         Real-time, peak, automatic peak three models of optional switch.
6.         Use USB interface and PC communications, synchronous test function can connect to the computer, computer synchronous display test force graph and the detailed test process, can save, print, doing all sorts of analysis.
7.         Peak holding, remove automatically function, remove time to set freely.
8.         Large storage, can save 99 groups of test data.
9.         Without automatic shutdown function, time can be set freely.
