Brand New ETCR2100+ Clamp on Ground Resistance Tester

Name: Brand New ETCR2100+ Clamp on Ground Resistance Tester
Brand: Graiagr
SKU: 130821475

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Graiagr

Model Number:

ETCR2100+

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Graiagr

Model Number ETCR2100+

Display Type Digital Only

Measuring Range 0.01-1200Ω

Testing Voltage 6V

Accuracy Class 1%

Operating Temperature -20℃-55℃

Dimensions 285mm*85mm*56mm

Brand New ETCR2100+ Clamp on ground resistance tester

PRODUCT DESCRIPTION

Characteristics:

1.Wider range: 0.01Ω-1200Ω

2.Resistance Resolution: 0.001Ω

3. Stored data: 99 groups.

4. Size of Jaw: ø32

5. Data upload: RS232 interface

6. Sound and light alarm

.Technical specifications

Function	Ground resistance test, Loop resistance test
Resistance Range	0.01-1200Ω
Resistance Resolution	0.001Ω
Highest Resistance Accuracy	±1%±0.01Ω
Current Range	0.00mA-20.0A
Current Resolution	0.05mA
Highest Current Accuracy	±2.5%±1mA
Data memory	99 Sets
Alarm Threshold Setting Range	Resistance: 1-199Ω
Alarm Sound and Light	“Beep-beep-beep” alarm tone, Alarm Symbol Flashing, Press AL key to turn on, turn off Alarm or set Alarm Threshold.
Interference Signal Recognition	“Beep-beep-beep” tone, NOISE symbol blinking
Working Temperature and Humidity	-20°C-55°C;20%RH-90%RH
LCD Screen	4 Digits LCD display, Screen L×W: 47mm×28.5mm
Clamp Size	Φ32mm
Clamp Opening Extent	32mm
Tester Weight	1160g (With batteries)
Clamp Dimension	L×W×T: 285mm×85mm×56mm
Protection Level	Dual Insulation
Structural Feature	Clamp CT
Shifting	Automatic shifting
External magnetic field	<40A/m
External electrical field	<1V/m
Single measurement time	0.5 second
Measured current frequency	50/60Hz Automatic measurement
Memory Full Indication	MEM symbol blinks when all 99 sets memory is full
Over Range Indication	Out of range indication “OLΩ”, “L0.01” or “OL A”
Auto Power-off	5 minutes after Boot up
RS232 Interface (Optional)	The data stored in the meter are uploaded to the computer through RS232 interface and data wire, Then generate report files
Accessories	Meter: 1 piece, Test ring: 1 Piece, Meter Suitcase: 1 Piece
