Help CenterConstant Voltage Power Supply PS-1505D 220V/110V Laboratory Power Supply
Related Products
-
Constant Voltage Power Supply PS-1503D 220V/110V Single Channel OutputUS$ 1 - 2MOQ: 1 Piece -
Voltage/current Adjust Knob With Rough and Meticulous Adjustable LAB dc Power Supply PS-1502D 220V/110V Single Channel OutputUS$ 1 - 2MOQ: 1 Piece
-
Voltage/current Adjust Knob With Rough and Meticulous Adjustable LAB dc Power Supply TPR-3030D 220V/110V Single Channel OutputUS$ 1 - 2MOQ: 1 Piece
-
Constant Voltage and Constant Current LAB dc Power Supply TPR-1510 220V/110V Single Channel OutputUS$ 1 - 2MOQ: 1 Piece
-
ST360 Professional IPTV Tester Meter DSL Line Test and IPTV Test TS and ISMAUS$ 1,000 - 1,500MOQ: 1 Piece
Specifications
1.Educational Laboratories2.Electronic production line
3.Communications industry
4.Product research
5. All other areas need
This series power supply is a kind of constant voltage power supply, which voltage can be adjusted from 0 to nominal value
Feature:
Signal channel output
Digital meter show the voltage and current values
Voltage adjust knob with rough and meticulous adjustable
Light and compact design
good for educational laboratories, safe for students to use
Low ripple and noise
Affordable and easy to operate
Have current limitation protection
Application:
1.Educational Laboratories
2.Electronic production line
3.Communications industry
4.Product research
5. All other areas need dc power supples
Specifications:
Model: PS-1505D
Input voltage: 220 V±10% 50Hz (setting switch at the back)
Output voltage: 0-15V
Output current: 0-5A
Operating Temperature: 0°C to 40°C
Relative humidity: <80%
Storage Temperature:-10°C to 70°C
Relative humidity: <70%
Constant voltage state:
Voltage stability: <0.01%+3mV
Load stability :< 0.01%+5mV
Recovery time :< 100μS
Ripple & noise : <1.0mVrms
Temperature coefficient: < 300PPM/°C
Mode |
Rated Output |
Dimension |
|
Voltage(V) |
Current(A) |
D×W×H(mm) |
|
PS-1502D |
0-15V |
0-2A |
190×128×145 |
PS-1503D |
0-15V |
0-3A |
190×128×145 |
PS-1505D |
0-15V |
0-5A |
190×128×145 |
