New DHC-100+ 220V Digital LCD Air Humidity Control Controller Range 10%~99% RH
New DHC-100+ 220V Digital LCD Air Humidity Control Controller Range 10%~99% RH
Description:
DHC-100+ adopts the integrated circuit type humidity sensor, with all the advantages of high sensitivity, fast response and excellent coherence, mainly used to measure, display and control the humidity. It specifies all the functions such as: switch the modes between humidification and dehumidification; control humidity by setting value and the difference value; output delay protection; calibrate the humidity value; alarm when sensor error or when humidity exceeds limit; proportional running time and stop time are adjustable when sensor error, keypad lock function.
Feature:
-Dual Function: humidification and dehumidification function selectable
-Measure, display and control the humidity
-Output delay protection; calibrate the humidity value; alarm when sensor error or when humidity exceeds limit;
-Proportional running time and stop time are adjustable when sensor error
-Adopt advanced Honeywell humidity sensor, with higher response speed, and better anti-interference capability
-Key-Lock Function
-Sensor can be demarcated, high accuracy.(useful when replace the sensor)
Specification and Size:
-Front panel size: 75*34.5mm
-Product size: 75*34.5*85mm
-Mounting size: 71*29mm
-Sensor wire length: 2m(include the probe)
Technical Parameters:
-Power supply: 110VAC, 50-60HZ
-Power consumption: <3W
-Measuring range: 0%RH~99%RH
-Resolution: 1%RH
-Control range: 10%RH~99%RH
-Accuracy:
±(5%RH+0.5digit) at 25 C
±(6%RH+0.5digit) at 0%RH~59%RH and ±(8%RH+0.5digit) at others, when 10 C ~ 40 C
-Sensor stability:±0.5%RH/year
-Sensor error delay: 1 minute
-Output contact capacity: 10A , Max. single-phase load is 0.25HP
-Front panel protection level: IP54
-Ambient temperature: 0 C~60 C
-Storage temperature: -30 C~75 C
-Relative humidity: 20~85%RH (No condensate)
-Color: as the pictures
-Easy and convenient to use
