NEW Cold Storage ETC-902 Temp Thermostat Temperature Controller
NEW Cold Storage ETC-902 Temp Thermostat Temperature Controller
Brief Description:
This mini Temperature Controller is an excellent and professional controlling device for maintaining temperature at a target range. It can measure andcontrol temperature for a wide range (-50 to 99 °C /-58 ~ 210.2 °F). This model could be used for cold storage application by controlling compressor & alarm.
This Temperature Controller equips a copy card interface (copy card not included). For those users have the copy card, they could set the parameters in batch very conveniently. It saves time and cost for batch production.
Note:
We supply the 220 ~ 240V version of this item. Please consider the voltage issue before bidding. We will provide appropriate plug adapter according to the plug shape of shipping location.
Features:
Mini and light weight design
Large and clear LED display
Wide Temperature Range (-50 ~ 99 °C/-58 ~ 210.2 °F)
Copy card interface for batch production
Password setting
Temperature alarm
Temperature calibration
Control temperature by setting the temperature set value and the different value
NTC sensor included
Wiring diagram for installation included
Specifications
Power Supply: 230V AC ± 10% 50 / 60 Hz
Rated current of the relays: 8A/220VAC
Ambient Temperature: -15 ~ 60 °C
Operating Relative Humidity: 20 % ~ 85 % (No condensation)
Storage Temperature: -15 ~ 60 °C
Temperature controlling range: -50 ~ 99 °C (-58 ~ 210.2 °F)
Display resolution: 1 °C / 0.1 °C (With the switch mode between integer and decimal )
Probe: NTC x1 included
Accuracy: NTC: ± 0.5 °C (-30 ~ 50 °C)
Cable length: 2 m (6.56 feet) including the sensor probe
Item dimensions: approx. 34.5 (W) x 77 (H) x 58 (D) mm (0.11 x 0.25 x 0.19 inch)
Mounting size: Length 71 x Width 29 (mm)
Item weight: 199 g (7.01 oz).
