NEW CDX-III Multifunctional Magnetic Powder Flaw Detector Portable Magnetic Powder Flaw Detector
US$ 400 - 700
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
GRAIGAR
Model Number:
CDX-III
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MS7282 AC DC Process Calibrator With True RMSK-type With LED Screen BlacklightUS$ 230 - 280MOQ: 1 Piece -
MS7281 Process Calibrator,True RMS Auto Range Process MeterK-type AC Current& DC AC Voltage With BacklightUS$ 220 - 280MOQ: 1 Piece
-
NEW NDT650 Ultrasonic Flaw Detection of a Variety of Defects Within the WorkpieceUS$ 3,000 - 4,000MOQ: 1 Piece
-
NEW NDT610 Digital Ultrasonic Flaw DetectorUS$ 2,800 - 3,200MOQ: 1 Piece
-
NEW NDT-510A Paint Coating Thickness Gauge (0-6000 - Um) in a Wide RangeUS$ 550 - 750MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
GRAIGAR
Model Number
CDX-III
Specifications
NEW CDX-III Multifunctional magnetic powder flaw detector Portable magnetic powder flaw detector
NEW CDX-III Multifunctional magnetic powder flaw detector Portable magnetic powder flaw detector
Product Introduction:
1.CDX-III multifunction magnetic detectors are magnetized magnetic detection device with a variety of ways.
2. The instrument uses AC and DC magnetization, SCR for non-contact switch, low noise, long life, easy operation, convenient, adaptable, stable.
3. It is in addition to all the advantages of having a portable models, but also has some strengths mobile models, expanding the use simplifies operation.
Probe features:
The instrument is equipped with four probes :( random except A, D, O three probes, special requirements);
a magnetic yoke probe:. (D type) it is equipped with a living joint, can be curved, flat workpiece inspection.
b Horseshoe probe:. (A-type) it can be a variety fillet, large parts of the inside and outside corner for local testing.
c ring:. (O type) can meet all energy into the workpiece to crack testing week, using it to detect fatigue cracks in the workpiece (fatigue cracks are perpendicular to the axis) is very convenient, it can be used on the workpiece demagnetization method carried away.
In short, the instrument is a combination of a variety of detectors, a wide range of functions and applications, especially for electricity arcing allowed to break the surface of the part of the testing.
Detailed parameters
Probe pole pitch:
1. yoke probe: 0-250mm adjustable
2. Horseshoe probe: 0-185mm adjustable
3. ring: Φ150 mm range
4. Working voltage probe: AC36V, DC8V
5. Probe current: about 8-12A
6. Power Operating voltage: AC220V ± 10% 50HZ
7. Sensitivity: can be clearly demonstrated (15/100) on the A-type standard grooved piece
8. Dimensions: 260 × 140 × 170mm
9. Weight: host weight 9kg, rotating magnetic field probe weight 3.5 kg, the probe yoke heavy 2.5kg, Horseshoe probe weight 2kg, 3kg weight ring.
