MS7218 Digital Portable Volt mA Process Calibrator 0.02% accurancy
MS7218 Digital Portable Volt mA Process Calibrator 0.02% accurancy
MS7218 Volt/mA Calibrator
Features
The fast, one-handed tool for loop checks.
This feature-rich solution combines the best features push-button and knob-base loop calibrator and offers:
· Large display and simple, quick-click interface for easy one-handed operation.
· Simultaneous mA and % readout for quick, easy interpretation of readings.
· mA accuracy of 0.025%, superior to other loop calibrators in this price range.
· 1 µA resolution for mA Source, Simulate and Measure.
· Innovative output adjustment dial with 1 µA and 100 µA resolution.
· 0-100% “Span Check” for fast switch between zero and full scale point.
· Selectable slow ramp, fast ramp, and step ramp to provide smooth outputs for valve slewing and loop functional tests. (Auto-Ramp Function provide single step(25%),slow or fast ramp output )
· 24 volt internal loop supply, so you can power and read a transmitter at the same time without carrying a DMM.
· Measures 0-10V DC & 0-100mV DC with accuracy 0.02%
· Output 0-10V DC & 0-100mV DC with accuracy 0.02%
· 4 - 20 mA or 0- 20 mA output range could be set manually.
· Rechargeable lithium ion battery pack.
· Push button 25% steps for fast, easy linearity checks.
Specifications
| Current Measure | Range: | 0 to 24 mA |
| Resolution: | 0.001 mA | |
| Accuracy: | 0.02% Rdg + 4 LSD | |
| Current Source | Range: | 0 to 20 mA or 4 to 20 mA |
| Accuracy: | 0.02% Rdg + 4 LSD | |
| Drive Capability: | To 1200 Ω at 20 mA | |
| Current Simulate | Range: | 0 to 20 mA or 4 to 20 mA |
| Accuracy: | 0.02% Rdg + 4 LSD | |
| Ext. loop voltage requirement: | 12-30 V | |
| Loop Power | While measuring mA, 24 V | |
| Voltage Measure | Range: | 0 to 10V DC |
| Resolution: | 1 mV | |
| Accuracy: | 0.02% Rdg + 4 LSD | |
| mV DC Measure | Range: | 0 to 100mV |
| Resolution: | 0.01mV | |
| Accuracy: | 0.02% Rdg + 4 LSD | |
| V DC Output | Range: | 0 to 10V |
| Resolution: | 0.001V | |
| Accuracy: | 0.02% Rdg + 4 LSD | |
| mV DC Output | Range: | 0 to 100mV |
| Resolution: | 0.01 mV | |
| Accuracy: |
0.02% Rdg + 2 LSD |
|
