Specifications
Digital Thermometer Temperature Thermocouple Calibrator MS7212
Digital Thermometer Temperature Thermocouple Calibrator MS7212
Model: MS7212
FEATURES
1. Measurement for TCs and RTDs
2. Ambient temperature compensation
3. Large LCD display
4. Smoothing of measurement
5. Selectable slow ramp, fast ramp, and step ramp to provide smooth outputs for valve slewing and loop functional tests.
6. 24 volt internal loop supply, so you can power and read a transmitter at the same time without carrying a DMM.
7. Charging and operating for this instrument can be conducted simultaneously (with a charger).
8. Ni-MH rechargeable batteries
Measure and Output
Function |
Measure |
Output |
DC Volt |
0-30.000V |
N.A |
DC Currency |
0-24.000mA |
N.A |
Loop power |
0-24.000mA |
N.A |
DC mV |
-10.000mV-80.000mV |
-10.000mV-80.000mV |
Resistance |
0-400.00 ohm 400.0-4000.0 ohm |
5.00-400.00 ohm 400.0-4000.0 ohm |
TC |
S, R, B, K, N, E, J, T |
|
RTD |
Pt100(385) Pt100(3926) Pt100(3916) Pt200(385) Pt500(385) Pt1000(385) Cu100(ITS) Cu50(ITS) |
|
