!!! Brand New!!! KYORITSU 3125 High Voltage Insulation Tester 5000V
US$ 1,200 - 1,217
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Japan
Brand Name:
KYORITSU
Model Number:
3125
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
JW3304N Optical Fiber Ranger OTDR Principle Tester Meter/Visual Fault LocatorUS$ 480 - 550MOQ: 1 Piece -
Oscilloscope Probe,P6020 Probe,P6040 Probe,P6060 Probe,P6100 Probe,20MHz Probe,60MHz Probe,80MHz Probe,100MHz ProbeUS$ 3 - 4MOQ: 50 Pieces
-
P124 Multimeter Test Probe Test Lead Wire Testing ProbeUS$ 1 - 1.5MOQ: 50 Pieces
-
P1020 Test Lead Wiring Test Probe Electronic Testing Probe Test Probe PinUS$ 1 - 1.5MOQ: 10 Pieces
-
P1013 Test Probe, Test Lead, Test Prod, Scope Probe, Oscilloscope Probe, Oscilloscope Clip ProbeUS$ 0.9 - 1.5MOQ: 10 Pieces
Place of Origin
Japan
Brand Name
KYORITSU
Model Number
3125
Display Type
Digital Only
Measuring Range
99.9MΩ~1000GΩ
Accuracy Class
|±10% rdg
Operating Temperature
-10~50
Dimensions
200(L) x 140(W) x80(D)mm
kyoritsu 3124 High Voltage Insulation Tester 1k~10kV variable
Product Description
| Range | Insulation resistance | Voltage measurement |
|||||||||||
| 500V | 1000V | 2500V | 5000V | AC/DC V | |||||||||
| Measuring range | 0.0~99.9MΩ 100~999MΩ |
0.0~99.9MΩ 100~999MΩ 1.00~1.99GΩ |
0.0~99.9MΩ 100~999MΩ 1.00~9.99GΩ 10.0~99.9GΩ |
0.0~99.9MΩ 100~999MΩ 1.00~9.99GΩ 10.0~99.9GΩ 100~1000GΩ (1TΩ) |
30~600V AC/DC [50/60Hz] |
||||||||
| Accuracy | |±5%rdg |±3dgt | |±5%rdg |±3dgt | |±5%rdg |±3dgt | |±5%rdg |±3dgt |±20%(100GΩ or more) |
|±2%rdg |±3dgt | ||||||||
| Short Circuit Current | 1.3mA approx. | ------- | |||||||||||
| Rated test Current | 1mA to 1.2mA at 0.5MΩ load |
1mA to 1.2mA at 1MΩ load |
1mA to 1.2mA at 2.5MΩ load |
1mA to 1.2mA at 5MΩ load |
------- | ||||||||
| Open circuit voltage | 500VDC
|
1000VDC
|
2500VDC
|
5000VDC
|
------- | ||||||||
| Maximum display | 999 Counts (1000 counts only at 1000GΩ) | 630 Counts | |||||||||||
| Current consumption | About 1000mA (During measurement) | 110mA approx. | |||||||||||
| Withstand Voltage Safety standard |
5320V AC for 5 seconds IEC 61010-1 CAT.III 600V, pollution Degree 2 |
||||||||||||
| Power supply | DC12V : R14×8 | ||||||||||||
| Dimensions | 205(L) × 152(W) × 94(D)mm | ||||||||||||
| Weight | 1.8kg approx. | ||||||||||||
| Accessories |
7165A (Line probe) 7224A (Earth cord) 7225A (Guard cord) 8019 (Hook type prod) 9159 (Carrying case [Hard]) LR14×8pcs (Alkaline battery size) Instruction Manual, Calibration Certificate |
||||||||||||
| Optional |
7168A (Line probe with alligator clip) 7253 (Longer Line probe with alligator clip) 8302 (Adaptor for recorder) |
||||||||||||
