Home > Instruments & Meters > Meter for Electricity > Voltage Meter > Portable Voltage And Continuity Testers UNI-T UT18A 12V-690V LED AC/DC Voltage Indication Auto Range Voltmeter Voltage Tester
Portable Voltage And Continuity Testers UNI-T UT18A 12V-690V LED AC/DC Voltage Indication Auto Range Voltmeter Voltage Tester
US$ 24 - 29
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT18A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Non-Contact AC Voltage Detectors UNI -T UT11A Digital Voltage Tester Test Pen 50-600V Motorcycle Voltmeter Voltimetro DoctorUS$ 3 - 6MOQ: 10 Pieces -
Non-Contact AC Voltage Detectors UNI -T UT11B Digital Voltage Tester Test Pen 50-600V Motorcycle Voltmeter Voltimetro DoctorUS$ 4 - 7MOQ: 10 Pieces
-
2015 Newest Design DCF-80 ELECTROMAGNETIC VALVE With High QualityNegotiableMOQ: 1 Piece
-
2015 Newest Design DCF 90 ELECTROMAGNETIC VALVE With High QualityNegotiableMOQ: 1 Piece
-
AZ9871 Handheld Wind Speed Meter Logger, Digital Anemometer PrinterUS$ 198 - 228MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT18A
Display Type
Digital Only
Measuring Range
12V ~ 690 V
Accuracy Class
0.5
Operating Temperature
-10~+65
Dimensions
272mm*85mm*31mm
Portable Voltage And Continuity Testers UNI-T UT18A 12V-690V LED AC/DC Voltage Indication Auto Range Voltmeter Voltage Tester
Detailed
UT18 series of test pen with measuring AC and DC voltage (including the three-phase alternating current) measurement, phase of three-phase AC power indicator, on-off test, RCD test, single pen measurement (can determine the zero line or wire), self checking, no battery detection and other functions.
Contrast
| Specifications | Range | Best Accuracy | |
| Model | UT18A |
UT18B | |
| LED AC/DC Voltage Indication (V) | 12V | 8V±2V | 8V±2V |
| 24V | 18V±2V | 18V±2V | |
| 50V | 38V±4V | 38V±4V | |
| 120V | 92V±6V | 92V±6V | |
| 230V | 174V±8V | 174V±8V | |
| 400V | 320V±10V | 320V±10V | |
| 690V | 550V±15V | 550V±15V | |
| Phase Rotation Test | Operating Voltage: 100V~690V | √ | √ |
| Frequency:50Hz~ 60Hz | |||
| Single Lead(L2)Voltage Detection | Operating Voltage:100V~690V | √ | √ |
| Frequency: 50Hz~ 400Hz | |||
| Continuity Test | Resistance: 0~100KΩ | √ | √ |
| Beeper and LED light Indicator | |||
| RCD Test | Operating Voltage: 230V(50Hz-400Hz) | √ | |
| Polarity Detection | Positive & Negative | √ | √ |
| self-inspection | All LED or LCD indicator | √ | √ |
| No power Test | Operating Voltage: 50VAC/120VDC~690VDC/AC | √ | √ |
| Features | |||
| IP65 | √ | √ | |
| Auto Range | All Range | √ | √ |
| Work Light | All Range | √ | √ |
| Low Battery Indication | Voltage Range: 2.2V-2.4V | √ | √ |
| Exceed Voltage | Voltage Range: 713V-788V | √ | √ |
| Auto standby | standby current <10uA | √ | √ |
| Silent mode | All Range | √ | √ |
| General Characteristic | |||
| Power | 1.5V Batteries(R03)× 2 (not included) | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 260g | ||
| Product Size | 272mm×85mm×31mm | ||
| Standard Accessories | Batteries | ||
| Standard Individual Packing | Blister, English Manual | ||
| Standard Quantity Per Carton | 30PCs | ||
| Standard Carton Measurement | 440mm × 295mm × 455mm (0.079 CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 17Kg | ||
Fitting
Batteries (not included)
