Home > Instruments & Meters > Meter for Electricity > Voltage Meter > Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test

Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test

Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test thumbnail-1
Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test thumbnail-2
Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test thumbnail-3
Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test thumbnail-4
Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test thumbnail-5
Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test thumbnail-6
Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test photo-1
Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test photo-2
Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test photo-3
Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test photo-4
Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test photo-5
Waterproof Type Voltage Tester UT15C Test Pen 0V~690V Single Lead Continuity Test Pencil Lead Test photo-6
Negotiable MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT15C
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name UNI-T
Model Number UT15C
Display Type Digital Only
Dimensions 275mm X 51mm X 30 mm

Waterproof Type Voltage Tester UT15C test pen 0V~690V Single Lead Continuity Test pencil lead test



Waterproof Type Voltage Tester UT15C test pen 0V~690V Single Lead Continuity Test pencil lead test





Introduction



UT15 Series test pen has a measure AC and DC voltage (with three-phase AC) measurements, three-phase alternating current phase instruction, on-off test, a single lead measurement (zero line can be determined or FireWire) and other functions


Suitable for: metallurgy, electronics, manufacturing, petroleum, defense, power, chemical and other industries. Also used to solve electronics, factory automation, power distribution and electromechanical equipment of complex issues.





Specification



Specifications Range Best Accuracy
Model   UT15A UT15B UT15C
LED AC/DC Voltage Indication (V) 12V 0~12V 0~10V 0~10V
24V 19V±2V 17V±2V 17V±2V
50V 48V±6V 35V±6V 35V±5V
120V 110V±20V 80V±20V 80V±15V
230V 200V±20V 165V±20V 165V±20V
400V 340V±30V 300V±30V 300V±30V
690V 520V±30V 510V±40V 510V±40V
Phase Rotation Test Operating Voltage: 0V~690V √  √  √
Frequency:50Hz~ 60Hz
Single Lead(L2)Voltage Detection Operating Voltage:100V~690V √  √  √
Frequency: 50Hz~ 400Hz
Continuity Test Resistance: 0~400KΩ   √  √
Beeper and LED light Indicator
Polarity Detection Positive & Negative √  √  √
Features
Water-Proof(IP65)   √  √  √
Auto Range   √  √  √
Work Light   √  √  √
Low Battery Indication Short circuit two leads,LED and beeper off when the bettery is low √  √  √
LCD AC/DC Voltage Display 24V~ 690V     ±(3%+8)
General Characteristic
Power 1.5V Batteries(R03)X 2 (not included)
LCD Size UT15C-23 X 12mm
Product Color Red and Grey
Product Net Weight 210g
Product Size 275mm X  51mm X  30 mm
Standard Accessories Batteries
Standard Individual Packing Blister, English Manual
Standard Quantity Per Carton 30PCs
Standard Carton Measurement 440mm×395mm×455mm (0.079 CBM Per Standard Carton)
Standard Carton Gross Weight 11.2Kg



Accessory



Batteries (not included)
