Product Details
| Place of Origin | Guangdong, China | Brand Name | UNI-T | |
| Model Number | UT242 |
Product Description
UNI-T UT242 UT-242 50mm Jaw size True RMS Power and Harmonics Clamp Meter Analyzer with USB interface
Introduction
Harmonics Clamp Meter is a sophisticated piece of equipment with a surprisingly easy to use design. The multi meter can measure AC voltages of up to 600 volts, and AC currents of up to 1000 amperes, in three measurement ranges.
The Power and Harmonics Clamp Meter can also be used to measure frequencies of between 40 and 80 Hertz, to an accuracy of 0.5%. The power clamp meter is also capable of measuring active power, apparent power and inactive power. Additionally, it can be used to measure electrical energy of up to 9,999 kWh.
The layout of this electrical multi meter allows you to take readings using just one hand. The large trigger, located on the left of the body, is used to activate the clamps. There are also 12 buttons on the front of the body, which are clearly labelled for quick identification. The body also has four ports, including a COM port.
The meter offers an impressive range of additional functions and features to enhance your professional experience. It features an LCD screen with a maximum display of 9,999, and an optional backlight for optimum viewing. It also has an auto-off function, which you can alter to suit your use of the meter. What’s more, it has a MIN/MAX value setting, and a USB port to allow you to transfer your data to a computer.
Specifications
| Specifications | Range | Best Accuracy | ||
| Model | UT241 | UT242 | UT243 | |
| AC Current (A) | 50A/250A/1000A | ±(2%+5) | ±(2%+5) | ±(2%+5) |
| AC Voltage (V) | 150V/300V/600V | ±(1.2%+5) | ±(1.2%+5) | ±(1.2%+5) |
| Frequency (Hz) | 50Hz-60Hz | √ | √ | √ |
| Active Power (W) | 0.01KW-600KW | ±(3%+5) | ±(3%+5) | ±(3%+5) |
| Apparent Power (VA) | 0.01KVAr-600KVAr | ±(4%+5) | ±(4%+5) | ±(4%+5) |
| Reactive Power (VAr) | 0.01KVA-600KVA | ±(3%+5) | ±(3%+5) | ±(3%+5) |
| Power Factor | 0.3-1 | ±(1%+2) | ±(1%+2) | ±(1%+2) |
| Phase Angle (°) | 0° - 360° | ±1° | ±1° | ±1° |
| Active Energy (Wh) | 1~9999KWh | ±(3%+5) | ±(3%+5) | ±(3%+5) |
| Features | ||||
| Display Count | 10000 | 10000 | 10000 | |
| Auto Range | √ | √ | √ | |
| Jaw Capacity | 50mm | 50mm | 50mm | |
| True RMS | √ | √ | √ | |
| Auto Power Off | √ | √ | √ | |
| Low Battery Indication | √ | √ | √ | |
| Data Hold | √ | √ | √ | |
| MAX/MIN | √ | √ | √ | |
| Data Logging | 999 | 999 | 999 | |
| USB Interface | √ | √ | ||
| LCD Backlight | √ | √ | √ | |
| Full Icon Display | √ | √ | √ | |
| Single-Phrase 2-Wires | √ | √ | √ | |
| 3-Phrase 3-Wires | √ | √ | √ | |
| 3-Phrase 4-Wires | √ | √ | √ | |
| Phase Sequence Test | √ | |||
| Harmonic Analysis | 1-20 | 1-20 | 1-20 | |
| Setup | √ | √ | √ | |
| Input Protection | √ | √ | √ | |
| Input Impedance for DCV | Around 5MΩ | √ | √ | √ |
| General Characteristic | ||||
| Power | 1.5V Batteries(LR6)×4 | |||
| LCD Size | 46mm X 42mm | |||
| Product Colour | Red and Grey | |||
| Product Net Weight | 601g | |||
| Product Size | 303mm X 112mm X 39mm | |||
| Standard Accessories | UT241-Test Lead, Batteries, Alligator Clips, Tool Box | |||
| UT242/UT243-Test Lead, Batteries, Alligator Clips, USB Interface Cable, Tool Box, PC Software CD | ||||
| Standard Individual Packing | Gift Box, English Manual | |||
| Standard Quantity Per Carton | 5 PCs | |||
| Standard Carton Measurement | 480mm X 372mm X 315mm (0.056CBM Per Standard Carton) | |||
| Standard Carton Gross Weight | 12Kg | |||
Accessories
Test Lead,
Batteries, (not included)
Alligator Clips,
USB Interface Cable,
Tool Box
PC Software CD
