Non-Contact Phase Detectors UT262C Sequence Measurement 3 Phase Detection Indicator Meter Tester LED Display Buzzer
US$ 50 - 90
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT262C
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Precision Pocket Electronic Scale MH-500 500g/0.1g Mini Weighing Scale 50-500gNegotiableMOQ: 10 Pieces -
Smart Sensor AR4105A Digital Earth Resistance Tester Meter 0-200 Ohm 2/3LinesUS$ 1 - 100MOQ: 1 Piece
-
Smart Sensor AR1392 Digital LCD Display Electromagnetic Field Radiation Detector EMF Tester Meter DosimeterUS$ 1 - 50MOQ: 1 Piece
-
Smart Sensor AR925 AR925 0.5~19999RPM Contact Digital Tachometer RPM Meter Digital Tach SpeedometerUS$ 1 - 25MOQ: 5 Pieces
-
Smart Sensor AR807 LCD Digital Hygrometer Thermometer Wet and Dry Thermometer Meter With Calendar & Clock AlarmNegotiableMOQ: 5 Pieces
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT262C
Non-Contact Phase Detectors UT262C Sequence Measurement 3 Phase Detection Indicator Meter Tester LED Display Buzzer
Introduction
The traditional method of measuring the phase sequence must be a three-phase terminal poke wire, three-phase sequence tables bare alligator clips or test pin connector to the bare three FireWire, and UT262 Series Clamp non-contact measurement, without poke wires, without contact with high voltage live wire exposed directly to the three ultra-induced high dielectric insulating covers jaws were clamped to the three-phase line of fire detection, greatly improving the field testing of the safety and operability, the effective protection of the operation personal safety of staff, improve the efficiency of the test! In addition to detecting the phase sequence,
UT262 series can also be used for live-ray examination, simple seized power, phase identification, phase judgment, break location of the search, the phase sequence detection, motor mounting, the ideal tool for line maintenance.
Specifications
| Specification | ||||
| Model | UT262A | UT262C | ||
| Phase Sequence | [Positive Phase] indicated by four phase detecting lights turn on clockwise and non-continuous beeping sound. | √ | √ | |
| [Negative Phase] indicated by four phase detecting lights turn on anti-clockwise and continuous beeping sound. | √ | √ | ||
| Missing Phase Detection | R-S or S-T light Off | √ | √ | |
| Live Power Detection | R-S or S-T light On | √ | √ | |
| Circuit Break Detection | R-S or S-T light Off | √ | √ | |
| Voltage Detection | R-S or S-T light On | √ | √ | |
| AC Voltage Range (V) | 70V-600V | √ | √ | |
| Frequency Range (Hz) | 40Hz-70Hz | √ | √ | |
| Features | ||||
| Clamp Opening | ø1.6~ø16mm | ø10~ø40mm | ||
| Display Mode | LED | LED | ||
| Power on Indication | √ | √ | ||
| Buzzer Indication | √ | √ | ||
| Auto Power Off | Automatically switch off after three minutes | √ | √ | |
| General Characteristic | ||||
| Power | 1.5V Batteries(R6)X 2 | |||
| Product Color | Red and Grey | |||
| Product Net Weight | 180g | |||
| Product Size | 70mm X 75mm X 30mm | |||
| Standard Accessories | Batteries | |||
| Standard Individual Packing | Blister, English Manual | |||
| Standard Quantity Per Carton | 20 PCs | |||
| Standard Carton Measurement | 800mm X 300mm X 400mm (0.096CBM Per Standard Carton) | |||
| Standard Carton Gross Weight | 9Kg | |||
Accessories
Battery (not included)
