Razor Barbed Tape Wire
Material: galvanized steel wire, galvanized plate, stainless steel wire, stainless steel plate.
Razor barbed tape wire is a kind of modern security fencing materials fabricated with razor sharp steel blade and high-tensile wire. Barbed Tape Wire can be installed to achieve the result of frightening and stopping to the aggressive perimeter intruders, with piecing and cutting razor blades mounted at the top of the wall, also the special designs making climbing and touching extremely difficult. The wire and strip and galvanized to prevent corrosion.
Curerrently, barbed tape has been widely used by many countries in military field, prisons, detetion houses, government buildings and other national security facilities. Recently years, barbed tape has apparently become the most popular high-class fencing wire for not only military and national security applications, but also for cottage and society and society fence, and other private buildings.
Razor Blade Specification:
(1) Straight Type Razor Wire
(2) Concertina Single Razor Wire
(3) Concertina Cross Razor Wire
(4) Flat Razor Wire
(5) Welded Razor Wire Mesh
Reference |
Blade Style |
Thickness |
Wire Dia |
Barb |
Barb |
Barb |
BTO-10 |
|
0.5±0.05 |
2.5±0.1 |
10±1 |
13±1 |
25±1 |
BTO-12 |
|
0.5±0.05 |
2.5±0.1 |
12±1 |
15±1 |
25±1 |
BTO-18 |
|
0.5±0.05 |
2.5±0.1 |
18±1 |
15±1 |
35±1 |
BTO-22 |
|
0.5±0.05 |
2.5±0.1 |
22±1 |
15±1 |
36±1 |
BTO-28 |
|
0.5±0.05 |
2.5 |
28 |
15 |
46±1 |
BTO-30 |
|
0.5±0.05 |
2.5 |
30 |
18 |
46±1 |
CBT-65 |
|
0.6±0.05 |
2.5±0.1 |
65±2 |
21±1 |
101±2 |
Barbed Tape Concertina (BTC); Barbed Tape Obstacle (BTO)
Standard materials are either galvanized or stainless steel.
Standard packages products are shown in the tables above, special specifications available on request.
Barbed Tape Wire Specification:
Outside Diameter |
No. of Loops |
Standard Length per Coil |
Type |
Notes |
450mm |
33 |
8M |
CBT-65 |
Single coil |
500mm |
41 |
10M |
CBT-65 |
Single coil |
700mm |
41 |
10M |
CBT-65 |
Single coil |
960mm |
53 |
13M |
CBT-65 |
Single coil |
500mm |
102 |
16M |
BTO-10.15.22 |
Cross type |
600mm |
86 |
14M |
BTO-10.15.22 |
Cross type |
700mm |
72 |
12M |
BTO-10.15.22 |
Cross type |
800mm |
64 |
10M |
BTO-10.15.22 |
Cross type |
960mm |
52 |
9M |
BTO-10.15.22 |
Cross type |
