Korea Darkhorse fusion splicer D19 optical fiber fusion splicer
Descriptions
Darkhorse new version D19is compact, simple, competitive fusion splicer for optical network engineering. Fast splice and heating time, anti-wind, anti-dust, anti-shock and waterproof suitable for indoor and field application.
D90S fusion splicer can be used for 250um, 900um, 3.0mm, insulated fiber as well as flat cable(indoor cable) and it is used core alignment.
Key Features
1.5.0" TFT-LCD scree, clear display.
2.Advance automatic core alignment(PAS).
3.7 seconds splicing time and 15s heating time.
4.Auto check quality of cleaved end-face.
5.High performance for circumstance.
6.Quick startup, fast fusion time.
7.Large electrode lifespan, more than 3500 arcs
8.Small bulk and light weight with optional function.
9.USB port&VGA interface
10. All-in-one fiber holders
Specifications
Splicing Method |
Core alignment (DACAS:Digital Analysis Core Alignment System) |
Average Loss |
SM(0.02dB) | MM(0.01dB) | DS(0.04dB) | NZDS(0.04dB) | G.657(0.02dB) |
Return loss |
> 60 dB |
Splice Time |
9s average SM | 7s SM Quick Mode |
Pull Test |
1.96~2.25N (standard) |
Electrode Lifespan |
> 3,500 arcs |
Applicable Fiber |
SM(ITU-TU.652/657), MM(ITU-TU.651), DS(ITU-T G.653),NZDS(ITU-T G.655), G657A, G657B 0.25mm, 0.9mm,2.0mm,2.4mm,3.0mm,FLAT(indoor cable) |
Cleaved Length |
Coating diameter < 0.25mm = 8-16mm, Coating diameter > 0.25mm = 16mm minimum |
Coating Diameter |
250-1000um |
Cladding Diameter |
80-150um |
Heating Programs |
Present several heating modes(40mm,60mm,heating adapters) |
Heating Time |
typical heating time 15S |
Protection Sleeve |
60mm, 40mm,heating adapters |
Data Output |
USB master device and COM |
Splice Programs |
100 user mode(SM-SM,NZ-NZ,DS-DS,MM62um,G657A, G657B,Quick etc) |
Splice Memory |
Up to 2000 records |
Battery |
Typical full cycle 200 Splice and Heat, 4200mAh |
Power Supply |
AC 100-240V input or DC 9-14V |
Monitor |
Dual camera, 90 degree, Color 5.0LCD monitor, with tempered glass |
Cameras |
2 CCD camera system |
Magnification |
Magnified: 260, 7 display modes for the splicing |
Fiber Display |
X/Y or XY simultaneously, single X.Y |
Weight |
2.0 KG (without battery) |
Size |
165.5 x 146.5 x 156mm (excluding rubber bumper) |
Wind Protection |
The max wind speed 15m/s |
Operating Environment |
Elevation 0-5000 meters, -10~50°c, 0~95% relative humidity |
Storage Condition |
Temperature -40 to 80°c, 0~95% relative humidity |
