Dredge Ball Joints :
DN900 Dredge Ball Joints :
DN900 dredge ball joint key features:
1.Pipe through ball construction
2.Ball joint to be welded to the dredge pipe
3.Low maintenance required
4.Exchangeable case liner
5.Exchangeable rubber seal
6.Ball joint can be customized to client’s requirements
Materials used:
Ball: ZG30Mn
Case: ZG30Mn
Gland: ZG30Mn
Liner: ZG30Mn
Seal: NBR
Lock: Q345
Technical Specifications
15 Degrees tilting angle | ||||||||||
|
10 Bar |
20 Bar |
30 Bar |
|||||||
Pipe ID (mm) |
Ball joint ID (mm) |
Height (mm) |
Width (mm) |
Weight (kg) |
Height (mm) |
Width (mm) |
Weight (kg) |
Height (mm) |
Width (mm) |
Weight (kg) |
900 |
954 |
900 |
1,766 |
2,611 |
1,088 |
1,891 |
3,659 |
1,237 |
2,000 |
4,788 |
18 Degrees tilting angle | ||||||||||
|
10 Bar |
20 Bar |
30 Bar |
|||||||
Pipe ID (mm) |
Ball joint ID (mm) |
Height (mm) |
Width (mm) |
Weight (kg) |
Height (mm) |
Width (mm) |
Weight (kg) |
Height (mm) |
Width (mm) |
Weight (kg) |
900 |
954 |
1,076 |
1,974 |
3,839 |
1,282 |
2,134 |
5,610 |
1,465 |
2,264 |
7,308 |
NOTE:We can provide customer with the best suitable solution and lowest cost , the dredge ball joints are designed in six different types, giving variations of tilting angle from 15 to 18 degrees and duties from 10 bar to 30 bar.
DN900 dredge ball joint drawing
