Digital tachometer SENTRY ST722 non-Contact and Contact Mode RPM Meter Laser Sighting

Digital tachometer SENTRY ST722 non-Contact and Contact Mode RPM Meter Laser Sighting

Digital tachometer SENTRY ST722 non-Contact and Contact Mode RPM Meter Laser Sighting



The revolutionary ST-72x series tachometer offers the accurate capabilities for measuring and recording the rotational, linear and surface speed. The non-contact concept is applied to both models in the series for hard-to-reach environment. Meanwhile, the easy-to-handle palm size designed for users who like to maneuver it with traditional method by contacting the object while the most accurate data is needed.



Features

Non-Contact and Contact Mode
Laser Sighting Operating Range up to 40 inches / 100 cm (Laser)
Auto Ranging / Fixed Decimal
Tripod Mounting Bushing
Low Battery Indicator

Specifications ST722 ST723
Rotation Speed (non-contact) 6.0 - 99999 rpm (rev/min) 6.0 - 99999 rpm (rev/min)
Rotation Speed (contact)   6.0 - 25000 rpm (rev/min)
Surface Speed (contact)
 		   0.6 - 2500.0 M/M (m/min),
0.7 - 2734.0 Y/M (yard/min),
23.6 - 98425 I/M (inch/min),
2.0 - 8202.1 F/M (feet/min)
Length (contact)    0.1 - 9999.9 M (m)
0.1~10936 YD(yard)
0.3~32808 FT(feet)
Total number of revolutions   1-99999REV(rev)
Accuracy 6.0 - 5999.9 rpm: ±0.01% and ±1 digit,
5999.9 - 99999 rpm: ±0.05% and ±1 digit) 		 6.0 - 5999.9 rpm: ±0.01% and ±1 digit,
5999.9 - 99999 rpm: ±0.05 and ±1 digit,
Surface Speed,Length 0.5%and ± 1 digit
Detection Laser diode Laser diode
Resolution 6.0 - 9999.9RPM
10000 - 99999RPM: 1 (RPM)		 6.0 - 9999.9: 0.1 RPM
10000 - 99999 rpm: 1 RPM
Response Time 1 secend 1 secend
Operating Temp. 0~50oC (32 to 122oF), 10 to 90% RH 0~50oC (32 to 122oF), 10 to 90% RH
Auto Power Off Automatically after approx. 30s Automatically after approx. 30s
MAX/MIN/AVG YES YES
Memory 40 Points 40 Points
Battery Type 9V(006P,IEC6F22,NEDA1604) 9V(006P,IEC6F22,NEDA1604)
Dimensions 147 x 49 x 29 mm (5.79'' x 1.93'' x 1.14'') 147 x 49 x 29 mm (5.79'' x 1.93'' x 1.14'')
Include Contact Adapters.
Weight 95g (3.35oz) Approx (without battery) 95g (3.35oz) Approx (without battery)
Contact Adapters : 50g(1.76oz)
Standard Accessories 9V Battery, Instruction manual,Reflective tape 15 x525 mm
(0.59'' x 20.67'' ), Carryimg Case		 Instruction manual, Cone adapter, Funnel adapter, Contact adapter, Master Wheel (10cm), Reflective tape 15x525mm (0.59”x20.67”), Carrying Case

Applications

Gear Box
Engines
Motors
Pumps
Compressors
Centrifuges
Couplings
Fans
Shafts
Grinders
Pulleys
