Product Details
Brand Name: | Leeb | Model Number: | Leeb 610C |
Product Description
Magnetic Flaw Detector Leeb610C
Function & Feature
- A special instrument for small portable nondestructive testing, nondestructive testing instrument is small principle design using magnetized workpiece into the crack.
- Stable and reliable performance and convenient operation.
- This product uses the coil wound on the probe directly on the induced magnetic field, magnetization, workpiece.
- Small volume, light weight, large lifting force and joint adjustable features.
- Optional probes available to users on specific artifacts.
- Output low voltage electrical, fit to the place where forbidden high voltage detector put in.
- Application Fields:
- Fit to be used for the detecting of Oil field, Boat making, Car making, Coal mine, Machine, Medicine, Airplane making and internal combustion engine parts etc.
- Can inspection for weld, weld, flat steel, pressure vessel, piping, shaft and complex shaped parts.
Technical Specification
- Input voltage: AC 220V±10%V
- Output voltage: AC 36V
- Output current: >10A
- Elevating capacity: >5kg
- Duty cycle:50%
- Sensitivity Type:A-type1#( specimens show clear)
- Overall dimension 230×160×56120mm(length*height*width)
- Weight: 5kg
- Standard configuration:Main machine, A- type magnetic yoke,power line, cable, packing list, manual, certificate.
