Home > Electrical & Electronics > Sensor > Pressure Sensor > CS-1 TYPE LOAD CELL Sensors Load Sensor Vehicle Load Sensor Material Hopper Weighers and Dynamo Metric Apparatuses.
CS-1 TYPE LOAD CELL Sensors Load Sensor Vehicle Load Sensor Material Hopper Weighers and Dynamo Metric Apparatuses.
US$ 50 - 80
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Model Number:
cs-1
Usage:
Pressure Sensor
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Brand New HF-10K Digital Force Gauge With S External Sensor 10KN Push Pull TesterUS$ 430 - 500MOQ: 1 Piece -
Digital Force Gauge HF-5K With External Sensor 5000N Push Pull Meter HF-5000US$ 320 - 400MOQ: 1 Piece
-
AST Manual Force Guage Test Stand AST-J for Push Pull Force Guage Maximum Load 500NUS$ 60 - 80MOQ: 1 Piece
-
New Dial Mechanical Push Pull Force Gauge NK-500,Precision Analog Force GaugesNegotiableMOQ: 1 Piece
-
NK-500 500 N/50 kg CE Certificate NK-20 NK-30 NK-50NK-100 NK-200 NK-300 Dial Mechanical Push Pull Gauge Force Gauge Meter TesterNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Model Number
cs-1
Usage
Pressure Sensor
Theory
Resistance Sensor
Output
Digital Sensor
CS-1 TYPE LOAD CELL Sensors load sensor vehicle load sensor material hopper weighers and dynamo metric apparatuses.
Materials: Alloy steel |
FUNCTION CHARACTERISTICS |
>Supported at two ends and receiving stress in their middle parts, our sensors feature a broadened range of weighing distance, good accuracy and stable performance. >Can be used in various electronic weighers for vehicles. material hopper weighers and dynamo metric apparatuses. >Automatic reset, resistant to deviation and laterality, easy to install and put into use. good inter changeability. |
configuration: |
Techincal Parameter
| Sensitivity | 2.0mv/v |
| Non linearity | ±0.02~±0.05%FS |
| Hysteresis | ±0.02~±0.05%FS |
| Repeatability | 0.02%FS |
| Creep | ±0.02~±0.05%FS/30min |
| Creep recovery | ±0.02~±0.05%FS/30min |
| Zero balance | 2%FS |
| Zero temperature coefficient | 0.03~0.05%FS/10℃ |
| Rated output temperature coefficient | 0.03~0.05%FS10℃ |
| Output resistance | 700Ω |
| Insulation resistance | ≥3000MΩ |
| Supply Voltage | 5~15V |
| Safe temperature range | -30~+60℃ |
| Safe overload | 130%FS |
| Defend grade | IP67 |
| Method of connecting wire | input:Red(+)Yellow(-) output:Blue(+)White(-) |
