ADT Horizontal Torsion Spring Tester Torsion Guage Test Stand





Product Description



ADT series horizontal torsion spring tester is a kind of intelligent multi-functional measuring instrument used for testing and inspection of torsion spring. With simple operation, high precision, easy to carry, complete functions, widely used in all kinds of electric, light industry, machinery manufacturing,research institutions, etc.



Main Features



1. High precision,high resolution,quick sampling speed and large screen show;



2.Upper and lower limit can be set,with sound and light alarm device;



3.Three kinds of parameters show (Torque value, Rotating angle, Spring stiffness);



4.Three units can be switched (N·m, kgf·cm, Ib·in);



5.Peak holding,remove automatically function, remove free time setting;



6.Without operation automatic shutdown function, time can be set free;



7.Using the USB interface and PC communications, synchronous test function can be connect to computer test.



Technology Parameter



Type

ADT-0.5

ADT-1

ADT-2

ADT-5

ADT-10

ADT-20

ADT-30

ADT-50

Measuring range

0.5N.m

1N.m

2N.m

5N.m

10N.m

20N.M

30N.M

50N.M

Division value

0.01mN.m

0.0001N.m

0.001N.M

Measuring angle range

                                        0~9999.9°

Angular resolution

                                           0.1°

Precision

less than 1%

Measured Spring Height

                                          150mm

Torque Plate Diameter



                                          Ø100mm

Load mode

 Manual control

Specimen method

                                       Spindle configuration

Power source

                                    AC220V,50HZ

Packing Size

 710*320*290mm

weight

                                          About 37.5Kg
