A/D/O Tire/Shore Durometer, Hardness Tester, Shore Durometer
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fruit Hardness Tester, Durometer, Fruit Sclerometer, Fruit Penetrometer GY-3NegotiableMOQ: 1 Piece -
Synthetic Rubber and Plastic Portable Hardness Tester , Handheld Digital Shore Durometer HS-ANegotiableMOQ: 1 Piece
-
Digital Display Rubber Shaw Shore Hardness Tester HS-CUS$ 100 - 300MOQ: 1 Piece
-
Micro Pointer Shore-A Hardness Tester , Handheld Shore Durometer for Low Hardness Plastic Leather Rubber Wax LX-AUS$ 20 - 40MOQ: 5 Pieces
-
Foam Hardness Tester,Sponge Hardness Tester,LX-F (0~2.5millimeters, 550mN~4300mNNegotiableMOQ: 1 Piece
Model Number
A/D/O
Specifications
A/D/O Tire/Shore Durometer, hardness tester, shore durometer
Product Description
A/D/O Tire/Shore Durometer
I.Introduction:
A Durometer
It is designed for testing the hardness of soft rubber,printer roller and other elastomer material.(ASTM--D--2240)
D Durometer
It is designed for testing the hardness of hard rubber,such as:thermoplastic plastics,bowling,plastic floor and so on.(ASTM--D--2240)
O Durometer
It is designed for the hardness of soft and elasticty material,spinning trunk rotation and soft grain structure materials.(ASTM--D--2240)
II.Parameters:
Model |
Force |
Pressure |
Shape of measuring head |
Length of Probe |
Dial Scale |
A |
8.1N |
1Kg |
Top angle(35angle) |
2.5mm |
0-100mm |
D |
44.5N |
5Kg |
Top angle(30angle) |
2.5mm |
0-100mm |
O |
8.1N |
1Kg |
Spheric radius2.38mm |
2.5mm |
0-100mm |
III.Notice:
1).Thickness of test specimen >6mm,no more than 3 layers; Test area >/=feet area(diameter 18mm).
2).Test 3 times and calculate the average as test result.
3).Usually,plz use A/D.When the hardness of A >90,plz use D or O.
