Specifications
slitting machine1. High speed, running stable
2. Materials:PE/PVC/PET/PP,ETC
3. Good quality
3. best price
1. HIGH SPEED AUTOMATIC SLITTING AND REWINDING MACHINE
USE:
This machine is used to check, rewind and cut all kinds of roll materials such as BOPP, PET, CPP and PVC.
FEATURE:
1. Imported PLC integrated control is used in electrical control system, human-machine communication is carried out by touch screen, Set and display working parameters a ccording to the requirements from different products.
2. Vector frequency-converting is adopted for rewinding, roll diameter is automatically calculated by PLC to achieve automatic tension control.
3. Vector frequency-converting is adopted for winding, active winding, roll diameter is automatically calculated by PLC to achieve automatic tension control.
4. Non-shaft pneumatic system for winding section is used. Width is adjusted by lead screw electrically,convenient load and unloading, high efficiency, automatic correction for winding.
5. Slitting functions: double tensioning shafts are used for rewinding, straight knife is used for slitting,smooth for the surface, and there is air exhausting device for waste.
6. Functions: Automatic stroboscope to observe printing images is equipped in the system. If there is any defects saw by eyes, press the button of defects, the button will automatically go back to defect image.(Automatic labeler is optional)
7. In the system, there are calculations of meter, roll diameter, automatic machine stop when lack ofmaterial etc.
8. The system has perfect mechanic, electric and pneumatic design, also good safety protection.
2. MACHINE DATA
Max.dimeter of unwinder φ900mm
max.diameter of rewnder φ600mm
width of unwinder 400mm-800mm
product width 40mm-800mm
paper core 3″(dia.φ76mm)
slitting speed 400m/min
accuracy ≤0.1mm
tension range 1~30kg
unwinder motor 2.2kW
rewinder motor 2.2kW(2pcs)
tracting motor 2.2kW
total power 11kW
3. PICTURES
