LX-A,LX-O,LX-D Tire Shore Durometer

LX-A,LX-O,LX-D Tire Shore Durometer thumbnail-1
LX-A,LX-O,LX-D Tire Shore Durometer photo-1
US$ 40 - 60 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
GRAIGAR
Model Number:
LX-A,LX-O,LX-D
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name GRAIGAR
Model Number LX-A,LX-O,LX-D

Specifications

1.LX-A,LX-O,LX-D Tire Shore Durometer
2.Test range: 0-100HA,0-100HC,0-100HD
3.Easy to carry
4.Plastic Box Packing

LX-A,LX-O,LX-D Tire Shore Durometer



I.Introduction:
A Durometer
It is designed for testing the hardness of soft rubber,printer roller and other elastomer material.(ASTM--D--2240)
D Durometer
It is designed for testing the hardness of hard rubber,such as:thermoplastic plastics,bowling,plastic floor and so on.(ASTM--D--2240)
O/OO Durometer
It is designed for the hardness of soft and elasticty material,spinning trunk rotation and soft grain structure materials.(ASTM--D--2240)

II.Parameters:

Model

Force

Pressure

Shape of measuring head

Length of Probe

Dial Scale

A

8.1N

1Kg

Top angle(35angle)

2.5mm

0-100mm

D

44.5N

5Kg

Top angle(30angle)

2.5mm

0-100mm

O

8.1N

1Kg

Spheric radius2.38mm

2.5mm

0-100mm

III.Notice:
1).Thickness of test specimen >6mm,no more than 3 layers; Test area >/=feet area(diameter 18mm).
2).Test 3 times and calculate the average as test result.
3).Usually,plz use A/D.When the hardness of A >90,plz use D or O.
LX-A,LX-O,LX-D Tire Shore DurometerLX-A,LX-O,LX-D Tire Shore DurometerLX-A,LX-O,LX-D Tire Shore DurometerLX-A,LX-O,LX-D Tire Shore DurometerLX-A,LX-O,LX-D Tire Shore Durometer
LX-A,LX-O,LX-D Tire Shore Durometer
