Wholesale HL200 Portable Rebound Leeb Hardness Tester Metal Meter Fast ShippingWholesale HL200 Portable Rebound Leeb Hardness Tester Metal Meter Fast Shipping
Introduction:
Die cavity of molds
Bearings and other parts
Failure analysis of pressure vessel, steam generator and other equipment
Heavy work piece
The installed machinery and permanently assembled parts
Testing surface of a small hollow space
Material identification in the warehouse of metallic materials
Rapid testing in large range and multi-measuring areas for large-scale work piece
*Compact metal case, suitable for use under poor working conditions. Test at any angle, even upside down.
*Wide measuring range. It can measure the hardness of all metallic materials. Direct display of hardness scales
HRB, HRC, HV, HB, HS, HL
*Large screen (128×64 dot matrix LCD), showing all functions and parameters. With EL background light.
*Large capacity memory could store 500 groups information.
*Datapro Software to connect with PC via USB port.
*Software calibration function.
*Outline; 132*76.2mm Weight; 345g
Technical Specifications:
*Error and repeatability of displayed value
No. |
Type of impact device |
Hardness value of hardness block |
Error of displayed value |
Repeatability |
1 |
D |
760±30HLD 530±40HLD |
±6 HLD ±10 HLD |
6 HLD 10 HLD |
2 |
D |
50±5 HLC 30±6 HLC |
±1 HRC ±2 HRC |
1 HRC 2 HRC |
3 |
D |
700±30HB 500±40HB |
±5 HB ±8 HB |
5 HB 8 HB |
*Measuring range; (170-960) HLD,(17-68.5) HRC,(19-651) HB,(80-976) HV,(30-100) HS,(59-85) HRA,(13-100) HRB
*Measuring direction: 360°
*Hardness Scale:HL,HB,HRB,HRC,HRA,HV,HS
*Display: dot matrix LCD, 128×64 dots
*Data memory:max. 500 groups (relative to impact times 32~1)
*Working voltage: 3V(2 AA size alkaline battery)
*Continuous working period: about 50 hours (With backlight off)
*Communication interface: USB1.1
