KTP crystal is mostly used as nonliner crystal for frequency doubling of solid-state Nd: YAG crystal or Nd: YVO4 crystal laser, as it has large nonlinear optical coefficients, wide angular bandwidth and small walk-off angle, broad temperature and spectral bandwidth. KTP crystal also has high electro-optic(E-O) coefficient and low dielectric constant, and large figure of merit, these features make it also widely used in electro-optic application.
Advantages of KTP Crystals:
·Large Nonlinear Optical(NLO) Coefficients
·Wide Angular Bandwidth and Small Walk-off Angle
·Broad Temperature and Spectral Bandwidth
·High Electro-Optic (EO) Coefficient and Low Dielectric Constant
·Large Figure of Merit for an Optical Waveguide Modulator
·Nonhygroscopic, Good Chemical and Mechanical Properties
Specifications:
Dimension tolerance: |
±0.1mm |
Flatness: |
l/8 @633nm |
Surface quality: Scratch/Dig |
10/5 |
Parallelism: |
better than 10 arc sec. |
Perpendicularity: |
better than 5 arc min |
Angle tolerance: |
q < 0.5°,f < 0.5° |
AR coating: |
dual band AR coating at 1064/532 nm for both faces |
residual reflectivity: |
R1064<0.1% ,R532<0.2% |
Clear aperture: |
>90% central area |
Transmitting wavefront distortion: |
less than l/8 @ 633nm |
Homogenity: |
δ≈10-6/cm |
Quality Warranty Period: |
one year under proper use |
