Radio Mask Communication and Talkable Mask With Anti Fog Lens for Military and Civil Defence - Ayonsafety

Specifications

Talk-Around Communication Mask

Brief Introduction:

The AYON Talk-Around communication system is the ideal choice for person-to-person and remote radio communications. The Talk-Around features a face piece mounted transceiver that can be used alone or in combination with a radio cable interface attached to a two-way radio, making it ideal for a variety of response situations including firefighting, disaster response, maintenance operations and manufacturing settings. The Talk-Around system provides real-time communications with push-to-talk (PTT). The Talk- Around is simple to operate and interfaces with a user’s existing radio, making it the perfect, low cost communication solution.

Outstanding Features of AYON-CM series mask:

- Wireless person-to-person communications

- Optional portable radio communications

- Easily toggles from wireless talk-around to portable radio modes

- Push-to-talk (PTT) design for suppression

- Easy to install, Easy to connect

- Optional hands-free VOX for HAZMAT scenarios

- Mounts easily to all existing full face mask

- Friendly gloved-hand operation

- Water resistant

- Heat resistant

- Compatible with virtually all radios

- Runs off AAA batteries

- 15 hour battery life

Technical Data:

- Material: Anti-allergy nature silicon

- Total Weight: 950g

-Working Temperature: -20℃ to +60℃

-Storage Temperature Range: - 40 ℃ to + 70 ℃

-Protection Grade: IP66-IP67

-Microphone with the microphone conversion delay:0.55s

-PTT Switch Life: 1000000 times

Technical Data of Directional Sound Amplifier:

-Standard Power: 1 w

-Maximum Output Power: 2 w

-Frequency Response: 300 Hz - 3400 Hz

-The battery voltage: DC3V

-Battery types: No. 7 battery

-Amplifying Work Current: 100-500 m

-Standby Current: less than 10 mA

-Speaker impedance: 8 Ω

-Sensitivity: 94 + 3 dB

-Pick-up: capacitor

-Frequency Response: 200-20000 Hz

-Output Impedance: 1 k

-Sensitivity: - 38 dB + 2 dB

Components Introduction:

1.   Loudspeaker

2.   PTT of intercom

3.   Intercom connecting wire

4.   Voice receiver

5.   Fixed screw

6.   Screw threaded hole

7.   Battery compartment

8.   Volume adjustment

9.   Amplifier switch

Using:

1: Check whether the amplifier is good, make sure it adheres to the mask tight and the connections are good; meanwhile make sure the respirator goes well. Wear the mask and respirator comfortably, and press the switch of the amplifier, if the indicator turns red, it means the amplifier is working well, if the indicator is not lit, please check whether the +/- of the battery is right or replace the batteries.

2: Wear the mask and respirator comfortably, and press the switch of the amplifier, if the indicator turns red, it means the amplifier is working well, if the indicator is not light, please check whether the +/- of the battery is right or replace the batteries.

3: The microphone should be installed inside the mask and breathing protection cavity, please avoid tearing, striking, etc. When using this product, please talk as usual, otherwise it might influence the communication.

4: When using the intercom, open the waterproof cover of outer intercom, plug in the connecting line and tighten it, and connect the other end with the intercom, press the PTT button when talking. (Use cover bag it when the product is not used.)

5: During normal use, if the spread voice becomes low or it appears the beeps, please replace batteries in time. The working time of the batteries provided is about 15 hours.

Easy Installation & Maintenance:

The Talk-Around system may be mounted on all existing Face mask by means of a single bracket. The bracket secures over the voicemitter housing, and all that is needed to lock the Talk-Around system in place is a single quarter turn. This system’s lightweight design means that there is no loss of face piece comfort or performance. The Talk-Around system is compatible with virtually all handheld portable radios with remote accessory connectors. The unit is water and heat resistant for ease of maintenance. To clean the unit, users may wash the Talk-Around system in a solution of warm water with mild detergent.

1: When necessary, the product could be cleaned with cleaning cloth and special cleanser.

2: If the amplifier is left idle for a long period, the batteries should be taken out to prevent the product from damaging.

3: The batteries should be replaced when they are dying, otherwise the product may be affected in bad way.

4: Only the maintenance of the batteries and the battery cover is described in this manual, other maintenance should be done in specific maintenance center.
