ANSI 56-4 Pin Type Insulators For High Voltage
US$ 7 - 7.5
MOQ: 2600 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Brand Name:
TSBXJ
Model Number:
56-4
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Pin Type Ceramic Electrical InsulatorsUS$ 7 - 7.5MOQ: 2500 Pieces -
55-3 Pin Type Insulator/ansi DesignUS$ 4.32 - 4.35MOQ: 5000 Pieces
-
Hot Sales 55-4 Suspension Percelain InsulatorUS$ 4 - 6.32MOQ: 5000 Pieces
-
Porcelain InsulatorUS$ 0.25 - 2.36MOQ: 5000 Pieces
-
Porcelain Insulator Used in Low Voltage LineUS$ 6.31 - 6.32MOQ: 5000 Pieces
Place of Origin
Jiangxi, China
Brand Name
TSBXJ
Model Number
56-4
Type
Insulator
Material
Porcelain
Application
High Voltage
Rated Voltage
v
Tensile Strength
v
56-4 Pin Type Insulators For High Voltage
Type |
56-4 |
||||
Main Dimensions(mm) |
H |
241 |
|||
h |
50.8 |
||||
D |
305 |
||||
d |
34.9 |
||||
R1 |
19 |
||||
R2 |
14 |
||||
Nominal Voltage(kv) |
46 |
||||
Creepage Distance(mm) |
685 |
||||
Minimun Flashover Voltage |
Power-frequency |
Dry(kv) |
140 |
||
Wet(kv) |
95 |
||||
50Impulse |
Positive(Kv) |
225 |
|||
Negative(kv) |
310 |
||||
Withstand Voltage |
One minute power-frequency |
Dry(kv) |
140 |
||
Wet(kv) |
95 |
||||
Impulse(kv) |
150 |
||||
Radio-Influence-Voltage Data |
Test Voltage to Ground(kv) |
30 |
|||
Maximum RIV at 1000kHzuV |
200 |
||||
Power-frequency puncture Voltage(kv) |
186 |
||||
Cantilever Failing Load(kN) |
13.6 |
||||
Weight(kg) |
10.8 |
||||
