Best-seller ,Disc Suspension Porcelain Insulator
- Shanghai/shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Jiangxi, China | Brand Name | TSBXJ, TSBXJ | |
| Model Number | XP-70, U70BL | Type | Insulating Ceramics | |
| Material | Other, Porcelain |
Product Description
Disc Suspension Porcelain Insulator(Normal Type)
Type | XP-70 | |
Class | U70BL | |
Unit spacing (H) mm | 146 | |
Nominal diameter (D) mm | 255 | |
Nominal creepage distance mm | 295/320 | |
Rated E&M failing load KN | 70 | |
Routine tensile load KN | 35 | |
Coupling size | 16A/16B | |
Impact strength N.m | 6 | |
Power frequency withstand voltage | Wet KV | 40 |
Dry KV | 70 | |
Dry lightning impulse withstand voltage KV | 100 | |
Power frequency puncture voltage KV | 110 | |
Radio interference voltage | Test voltage to groud KV | 10 |
Max.RIV at 1MHZ uv | 50 | |
Mass per 100pcs kg | 470/490 | |
Applicable standard : GB IEC AS BS | ||
