Specifications
5MP Document Scanner*High definition projection
*High speed scan
*Contrastive teaching
*Work with multi touch board
ELOAM Dual Lens Document Camera HT-IR5300 is the revolution of classroom document camera in the 21st century. It is portable style while have full function of the troditional document camera, besides, it has its special function that make the contrastive teaching available.
Main Features:
1.Dual Lens,horizontal(3MP) and vertical (5MP) .
2.Hi definition scan the real objects , also can high speed scan the papers .
3.Annotate on the picture of the object/desktop by whiteboard software .
4.Contrastive teaching available, compare different picture/video by devided screens.
5.Recording with voice
6.Easily convert the pictures/files to PDF file
7.Support zoom in/out by working with the Multi Touch Interactive Whiteboard
8.Brand new product, no same products in the market.
9.Customizable color available in bulk order
Specification
Product model |
S500L |
Scan size |
A5, A4 (The scan size can be bit bigger than A4, but must be less than A3 size) |
Copy speed |
1s |
colour |
24 bits |
Main camera Resolution |
5.0 Megapixels(2592*1944) |
Second camera |
3.0 Megapixel (2048*1536) |
Image format |
JPG, PDF |
Video format |
AVI,FLV |
interface |
USB2.0 |
Image management |
Brightness adjustment exposure adjustment,sharp adjustment, colour adjustment,refine adjustment,colour tone adjustment, image cut |
Light source |
Super bright LED, natural light |
Patent technology |
1.Bright image technology in weak light 2.Real time zoom in/out on video and symbol remark technology 3.Double video combination in real time.Screenshotsynchronization technology 4.Built in mircrophone. Real time voice instruction. Recording simultaneously |
Detail Features
- Scan size: A5, A4
- Video display: Display modes: Actual size,,suitable for screen, full screen .
- Objects shooting max: 2592*1944
- Head portrait shooting max: 2048*1536
- Speed: Max 30 frame/s.
- Colour::24 bit
- Auto adjust white balance,auto exposure., rotate..
- Dynamic real time rotate and real time zoom in/zoom out.
- Brightness, contrast,saturation adjustment
- Image management: Image revising, rotating, change the size, mirror, brightness adjustment, contrast, saturation,gray, wipe off black edge, rectify slanting, image filtering, bianaryzation, reverse, sharp, image cut. Cut any area of image to copy, save or save as.
- Image saving format: JPG.
- Image file management
File management: new, delete, revise, support many level files. Image binding. Binding a album by some images. Can delete, change the order by mouse drag. Import image. Select one or more to import to USB or other local disc.. Move file, print. - Other specification
Sensor: CMOS 1/3inch 2592*1944 (IR-5300). View angle 50°. Lens:F2.8. Interface:USB 2.0 with UVC. Power: supply by USB. Power consumption: 5V.
Application: interactive classroom teaching, interactive demostrate, enterprise training, research project, interactive media, long-distance eduation, multi-locations interactive
Accessories
USB Cable 1Piece
Software CD 1 Piece
Hardware Installing
Connect the documet camera with PC by USB cable, install the driver, then you can use.
