Features of Henan Better cheap than used concrete mixer trucks for sale
1.Original agitating vane, non-feeding small cone design with lower fuel consumption, bigger work-saving and less discharging remain;
2.Self-manufactured excellent chassis with special-purpose, more reliable & safer;
3.Separated hydraulic system with higher stability and more powerful cooling;
4.Double operation system makes feeding and discharging easy ;
5.Unique jack-up truck mixer design meets the demands of third-class gradation mixing, transport as well as discharging.
6.High-intensity drum material, featuring better wear-resistance and long service life;
Parameter
| Model | Better Foton 12m3 | Better Foton 14m3 | Better Foton 16m3 |
| Mixing capacity | 12m3 | 14m3 | 16m3 |
| Tank Volume | 17.93m3 | 20.1m3 | 24.1m3 |
| Feeding speed | ≥3.5m³/min | ≥3.5m³/min | ≥3.5m³/min |
| Discharging speed | ≥3m³/min | ≥3m³/min | ≥3m³/min |
| Residual ratio of discharging | ≤0.5% | ≤0.5% | ≤0.5% |
| Water supply system | Air pressure | Air pressure | Air pressure |
| Water tank volume | 400 | 400 | 400 |
| Dimension | 9880*2496*3920 | 10300*2496*3920 | 10300*2496*3920 |
| Max speed | 80km/h | 80km/h | 80km/h |
| Chassis model | BT1995 | BT1998 | BT1998 |
| Engine power | 247 / 276hp | 247 / 276hp | 247 / 276hp |
| Emission standard | Chn Ⅲ | Chn Ⅲ | Chn Ⅲ |
| Overall weight | 25000kg | 31000kg | 31000kg |
| Rated load | 15000kg | 16600kg | 16600kg |
| Wheelbase | 3225+1350mm | 3225+1350mm | 3225+1350mm |
| Approach angle | 25° | 25° | 25° |
| Departure angle | 13° | 13° | 13° |
| Maximum gradeability | 0.3 | 0.3 | 0.3 |
Photos
Concrete transport considerations
1, the time concrete mixer truck transporting concrete batching plant can not exceed the stipulated time. Not long time mixing tube stops to prevent segregation of concrete produced. Drivers should always observe the concrete situation, abnormal timely informed the control room, to make the application process.
2, when the car is equipped with concrete, dead time in the field not more than one hour, such as overtime require on-site person in charge shall immediately give a timely manner.
3, concrete mixer truck transporting concrete slump of not less than 8cm. From concrete to discharge into the tank, not more than two hours at high temperatures, rainy weather temperature is low, not more than 2.5 hours.
4.Before the concrete is discharged, such that a mixing tube is rotated at 10-12 rpm / min speed minutes, and then discharge.
40'' standard export packing Containers or as your order
1.Use crane to load into the container
2.Wire cable fastened inside the container
3.Cork wood to forbid collision
1.Pre-sale service:
TiTi Han will give you suggestive productivy, as your request to make a blueprint for you, then make the accuracy quotation, let you know all the parts of the concrete batching plant.
2.Sale service:
Our advanced technicians will be sent your jobsite to guide operation and installation. Then teach how to use the machines, field test accuracy, make sure the plant is all well down,
3.After-sale service:
We give you one year warranty, when something wrong in the plant, we will teach you how to fix it, if needs, our engineers can come to your work site to help you fix it.
Henan Better Heavy Industry Co., Ltd is one of the largest manufacture in the production of construction machinery with a long history, strong technical force, well-equipped and advance technology. Our factory is located in the beautiful central plains hinterland—Zhengzhou city,Henan prov, east of the third ring Rd, west face to loop expressway, has a convenient transportation. Our company has more than ten years of innovation and development, the company has become a set of concrete mixing plant, concrete mixer, concrete batching machine, dry mortar production line, steel bar straightening machine production, sales and R&D integrated technology oriented enterprises. Our products sell well all over the country and exported to the Outer Mongolia, Russian, Philippine,Macedonia,Tanzania, Cyprus etc and won overseas customer’s trust and good reputation.
1.Where do your customers come from?
Our clients includes those Fortune 500 companies like China Water Agency, China Sinohydro Corporation, Henan Construction Engineering Co, China South-to north Water Project and lots of cities and towns housing construction companies.
2.What about your International Market?
We have established overseas project in more than 19 countries and regions, just like Outer Mongolia, Russian, Philippine,Macedonia,Tanzania, Cyprus etc and won overseas customer’s trust and good reputation.
3.What is the payment term?
T/T L/C Paypal Western&Union cash
4.How to transport and install this production line equipment?
40'' standard export packingcontainers or as your order.
Use crane to load into the container,wire cable fastened inside the container,cork wood to forbid collision.
5.What are your main products?
(1)Concrete mixer plant,concrete mixer machine,JZC/JDC/JZM portable concrete mixer
(2)Dry mortar mixer plant,dry mortar mixer machine,dry mortar mixer auxiliary equipment.
(3)Conrete batch plant,cement silo,sand dryer,sieving machine,bar straighting machine,control computer.
