Large Screen PH Meter PHS-3G Acidity Meter With Electromagnetic Mixing Ph Measurement

Large Screen PH Meter PHS-3G Acidity Meter With Electromagnetic Mixing Ph Measurement photo-1
US$ 450 - 500 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Graigar
Model Number:
PHS-3G
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Graigar
Model Number PHS-3G

Specifications

large screen PH meter PHS-3G acidity meter with electromagnetic mixing Ph measurement

large screen PH meter PHS-3G acidity meter with electromagnetic mixing Ph measurement

large screen PH meter PHS-3G acidity meter with electromagnetic mixing Ph measurement

Overview

Laboratory pH meter use electrode method to measure pH value of water solution which directly reflects the acid and alkali level. To match with particular ion selective electrode, it can measure electrode potential mV value of relevant ion. Meter is suitable in the field of environmental protection, water quality analysis, medical and health, food safety, scientific research, higher education, biological agriculture and forestry, etc…. We have various laboratory pH meter and on-site pH meter to meet different needs of measuring precision requirement. In which high-tech intelligent pH meter adopts large touch LCD screen, English display for rapid and easy operation. It has the function of automatic recognition several standard buffer solutions, multi-point calibration. The calibration procedure is easy and rapid and the result is more accurate. With automatic temperature compensation, automatic calculation of theoretical percentage of electrode slope and power failure protection functions. To match with data collecting software(1.1DC), it can communicate with computer. To choose particular electrode, it can measure pH value of ultra pure water, pure water and boiler water. The operation temperature is 5.0~60.0C.



Characteristics

Microprocessor technology and dot matrix LCD, easy to operate.

Automatic temperature compensation, automatic calibration and automatic calculation of percentage theoretical slope of electrodes.

Measurement results can be stored, deleted, consulted and printed. It can store 50 sets of measurement data.

Protection from electricity cutting off. The stored data and parameters will be kept even if unusual electricity cutting off happens;

One point or two points automatic calibration can be conducted on the meter with five types of pH buffer solution selected by users within the temperature range of 0-60 C.

With RS-232 interface for connecting TP-16 printer using DC 1.0 software of data-collection to communicate with computers.

Users can measure the pH value of ultra-pure water, pure water and boiler water through adjustment of equipotential point and special electrodes selected.

Equipped with pH combined electrode  and temperature sensor of T-818-B-6 made by Rex.



Specifications



      Model

Specifications

PHS-3G

Parameters

pH /mV(ORP)

Range

pH

-2.00~19.99

mV

±1999

Resolution

pH

0.01

mV

1

Accuracy

pH

±0.01±1 bit

mV

±0.1%F.S.

Stability

  (±0.01pH±1 bit)/3h

Temp compensation

Manual(0.0~60.0)C

Calibration

pH: up to two

Buffer recognition

Automatic: 4.00, 6.86, 9.18

Display

LCD

Stir

Electromagnetic stirring

Power

AC (220±22)V, (50±l )Hz

Case outside serial No.

WXS-A010-2

Dimension (mm), Weight(kg)

210×320×90, 2

large screen PH meter PHS-3G acidity meter with electromagnetic mixing Ph measurement
