Home > Products > Analyzer Instruments > SM6234E Non-Contact Digital Laser Photo Tachometer Wide Measuring Range,high Accuracy Auto Range RPM Meter With LCD Display
SM6234E Non-Contact Digital Laser Photo Tachometer Wide Measuring Range,high Accuracy Auto Range RPM Meter With LCD Display
- shenzhen
- T/T Credit Card PayPal
You May Like
-
OCEA SPD202/Ex Flammable Gas Detector Meter Digital Combustible Gas Alarm Meter
-
86555-Benchtop PH/ORP/Cond./TDS/Salinity Printer,Industrial Desktop pH Acidity Tester,AZ86555
-
Industrial Desktop pH Acidity Tester ,AZ-86502 Instrument Desktop pH Tester AZ86502
-
AZ86505 Benchtop PH/ORP/TDS/conductivity/salinity Meter
-
Industrial Desktop pH Acidity Tester Laboratory Tester PH Meter,AZ-86501Instrument Desktop pH Tester AZ86501
-
Pen Type ORP Meter ,big LCD ORP Pen 8552, IP65 Water Proof ORP Meter
Product Details
| Place of Origin | Guangdong, China | Brand Name | GRAIGAR | |
| Model Number | SM6234E |
Product Description
SM6234E Non-Contact Digital Laser Photo Tachometer Wide measuring range,high accuracy auto Range RPM Meter with LCD Display
ITEM SPECIFICATION
The tachometer uses microcomputer(CPU) technique; photoelectric technology, anti-jamming technique and junction laser technique for non-contact measurement of rotation speed(RPM), frequency(Hz) and total cycle(Total).
Features:
Wide measuring range and high resolution.
Large screen LCD display provides clear reading.
Automatically save Max, Min and last values, also save 96 sets of continuous data.
The tachometer starts to store data after first reading.
Low battery voltage indication.
Smooth housing design, comfortable to hold and use.
The tachometer uses microcomputer(CPU) technique; photoelectric technology, anti-jamming technique and junction laser technique for non-contact measurement of rotation speed(RPM).
Specifications:
Color: Dark Blue + Dark Gray
Material: Plastic
Display: 5 digital, 18mm LCD
Range: 2.5~99999 RPM; 0.05~1666Hz; 1~99999 Count
Resolution: 0.1 RPM (2.5~999.9RPM); 1 RPM (above 1000RPM); 0.01Hz(0.05~99.99Hz); 0.1Hz(above 100Hz)
Accuracy: ±(0.05%+1 digital)
Sampling Time: 0.8s(over 60RPM)
Range Select: Auto-Ranging
Time Base: 6MHz Quartz Crystal
Memory: Max. Value, Min. Value, Last Value
Detecting Distance: 50mm-500mm
Power: 3 * 1.5V AA Batteries (not included)
Item Size: 155 * 70 * 35mm / 6.1 * 2.75 * 1.38in (L * W * H)
Item Weight: 143g / 5.06oz
Package Size: 20 * 15 * 5.5cm / 7.87 * 5.9 * 2.16in (L * W * H)
Package Weight: 424g / 14.96oz
Package List:
1 * Digital Tachometer
3 * Stickers
1 * Screw
1 * User Manual (English)
