Small Label Cutting Machine With Waste Removal Feature

FOB Price

US$ 10,000 - 20,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Commodity
Packaging Type	Case	Packaging Material	Wood
Automatic Grade	Automatic	Driven Type	Electric
Voltage	220V 50HZ	Power	250w
Place of Origin	Shanghai, China	Brand Name	SPIC small label cutting machine
Model Number	small label cutting machine, small label cutting machine	Weight	110/80KGS
Dimension(LWH)	114X79X69CM	Certification	CE ISO9001
After-sales Service Provided	Engineers available to service machinery overseas

Automatic paper roll die cutting machine with waste removal feature

Suitable for prototyping or small production
Contour cutting is performed automatically
Perfect for low-cost, on-demand, short run labels, specialty labels of any shape, and helps reduce inventory.
Max. cutting straight-line speed of 960mm/min Max. cutting curve-line speed of 600mm/min
Max. media of 16”
Max. cutting width of 12”
Max. cutting length of 12” for one time
Motor power: 25watt
Max. down force: 750g (3g/step)
CPU: 64 BIT dsp 32m Flash
Encoder signal: physical 1016 line/round, logical 4064 line/round
Repeating precision: 0.082mm
Noise: 35 dB OR LESS
Ambient temperature: 5 - 35 degrees
HPGL commands
With feeding system and rewinding system
Servo control system, fast and quiet
Direct USB, easy and reliable
SD card memory: 4G, no need computer to run machine
Warranty: 12 months package: wooden box,114x79x69cm 110/80KGS

Picture from customer :

Note: Machinde sizes can be customzied according to customers.
