500 Amp Mma Arc Welding Machine Zx7-160 Mma dc Welder Inverter

500 Amp Mma Arc Welding Machine Zx7-160 Mma dc Welder Inverter thumbnail-1
500 Amp Mma Arc Welding Machine Zx7-160 Mma dc Welder Inverter thumbnail-2
500 Amp Mma Arc Welding Machine Zx7-160 Mma dc Welder Inverter thumbnail-3
500 Amp Mma Arc Welding Machine Zx7-160 Mma dc Welder Inverter thumbnail-4
500 Amp Mma Arc Welding Machine Zx7-160 Mma dc Welder Inverter thumbnail-5
500 Amp Mma Arc Welding Machine Zx7-160 Mma dc Welder Inverter thumbnail-6
500 Amp Mma Arc Welding Machine Zx7-160 Mma dc Welder Inverter photo-1
500 Amp Mma Arc Welding Machine Zx7-160 Mma dc Welder Inverter photo-2
500 Amp Mma Arc Welding Machine Zx7-160 Mma dc Welder Inverter photo-3
500 Amp Mma Arc Welding Machine Zx7-160 Mma dc Welder Inverter photo-4
500 Amp Mma Arc Welding Machine Zx7-160 Mma dc Welder Inverter photo-5
500 Amp Mma Arc Welding Machine Zx7-160 Mma dc Welder Inverter photo-6
US$ 193 - 194 MOQ: 1 Box
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
TOP GIN
Model Number:
TG700-6
Contact Supplier Request Quote Chat Now
Shangchin Electronics Corp.
Payment & Shipping
Payment Methods:
Port of Shipment:
Taichung
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Taiwan, China
Brand Name TOP GIN
Model Number TG700-6
Output Power Other, 2.2KW~75KW
Output Type Triple
Size 302*150*183(mm)~565*380*295(mm)
Weight 3KG~44KG
Input Voltage 380V
Output Voltage 380V
Type DC/AC Inverters
Output Frequency 400HZ
Output Current 4.2A~130A

500 amp mma arc welding machine zx7-160 mma dc welder inverter







[Performance]

  • Starting torque compensation (load detection value input method)
  • Control power control (battery operation)
  • Multi-speed operation (up to 9 speed)
  • Automatic S word deceleration run


[ Specification ]



Control Characteristics

 TG700 permanent magnet servo controller
Control mode   High carrier sine wave PWM vector control
Speed control accuracy   ±0.01%
Speed control range   1:1000
Maximum torque   455% of the rated motor torque
Speed setting signal   '-10~10V,0~10V,4~20mA
Deceleration time   Acceleration, deceleration individual settings, set the unit 0.01 seconds
S word set   Starting, acceleration, deceleration start, stop of each individual set point
The main control functions

  Starting torque compensation (load detection value input method)

  Control power control (battery operation)

  Multi-speed operation (up to 9 speed)

  Automatic S word deceleration run
Protective function
Motor protection   Electronic thermal protection devices
Instantaneous overcurrent   More than 300% of the rated output current of about
Fuse protection   Fuse stop
Overload capacity   150% of one minute, 10 seconds 200%
Overvoltage   Stop when the main circuit DC voltage 400V / 820V or more
Insufficient voltage   Stop when the main circuit DC voltage 220V / 380V or more
Instantaneous power compensation   15ms or more stops (50% load) when
Fin overheat   Thermistor protection
Antistall   Acceleration and deceleration, stall prevention operation
Ground protection   Electronic circuit protection
Charging display   The main circuit DC voltage drops to 50V before lighting display
Environmental conditions
Venues   Indoors (no corrosive gas, dust, place)
Humidity   Below 90% RH (non-condensing)
Storage temperature   -20 ~ 70℃
Ambient temperature   -10 ~ 50℃
Altitude   1000m below
Vibration resistance acceleration   Vibration frequency less than 20Hz when 9.81m / S (1G)

  20-50Hz when 1.96m / S (0.2G) until



[SIZE]

500 amp mma arc welding machine zx7-160 mma dc welder inverter

500 amp mma arc welding machine zx7-160 mma dc welder inverter

500 amp mma arc welding machine zx7-160 mma dc welder inverter500 amp mma arc welding machine zx7-160 mma dc welder inverter500 amp mma arc welding machine zx7-160 mma dc welder inverter500 amp mma arc welding machine zx7-160 mma dc welder inverter500 amp mma arc welding machine zx7-160 mma dc welder inverter
