2016 China cheap offset printing machine
Continuous Water- Feeding Device:
452’s continuous dampening system is equipped with cooling water circulation device which ensures there always will be water film on the plates, even if no ethyl alcohol supplied. Such kind of device can meet high-qualified printing.
Continuous Paper- Feeding Device:
Adopt the newest designed, small type continuous paper- feeding device
Pneumatically Controlled Clutch Structure:
The cylinders and the forme rollers are controlled pneumatically, which not only simplifies the clutch structure but aslo improves the durability of the whole machine.
Tri-diameter Paper-transporting Cylinder;
Double-diameter pressing cylinder, tri-diameter paper-transporting cylinder and the main precisely assembled drive system guarantee the printing quality and accurate register.
Specifications:
Certifications
Mode |
252 |
Maximum size of paper |
520*365mm |
Minimum size of paper |
257*182mm |
Maximum printing area |
505*350mm |
Thickness |
0.04--0.4mm |
Paper- feeding |
Continuous paper feeding |
Paper- feeding board capacity |
500mm |
Paper delivering board capacity |
420mm |
Dampening system |
Continuous water feeding device |
Printing plate size |
510*400*0.15mm |
Number of ink roller |
16 rollers (include 3 ink roller ) |
Rubber blanket |
510*452*1.90mm (belt metal jig) |
Printing speed |
3000--12000pages /Hour |
Main power |
Main engine: 3.7Kw/Air pump: 0.75Kw/Air compressor: 0.75Kw |
Power source |
380V 50/60Hz 45A |
physical size |
2410 (long) *1995 (width) *1650 mm |
Machine weight |
3200Kg |
We Promise: All your machines will be packed in steady seaworthy package.
Shanghai Printpack dedicate to provide "value+" service to those who in need of quality and resonable priced equipment for printing and packaging industry.
Our team of seasoned professional consultants are willing to offer range of products in print & pack machinery of hi performanced, as well as optimizing supply chain management for overseas customer sourcing from China.
We are willing to play as an important partner for those who got inspired by China's growth.
