Custom mechanical helical gear with small size
| PIC No. | DSC05577 |
| Brief Description and Advantages | Hard Tooth |
| Notes | This material has good hardenability and machinability,it would be harder in surface and have better wear-resisting performance after heat treatment for large section parts. In order to make sure that the products meet the requirements of the drawings, our engineers tracked the manufacturing process of this batch gears. And the profile modification and axial modification were applied to gears after grinding, which effectively improved the perfomance of gear mesh,reduced the meshing impact and the noise, made tooth width load equally distributed, finally improved the bearing capacity. |
| Tooth Profile | Involute |
| Material | 17CrNiMo6 |
| Process | Forging+Carburizing and Quenching+Internal Grinding+Grinding+Wire Cutting; |
| Pressure Angle | 20° |
| Gear Quality Level | DIN 6 |
| Type | M=10,Z=33,a=20°,β=7.5°,x=+0.04,right hand; |
| Brand | YL |
1. Products: high precision involute cylindrical gears, gear boxes, precision sheet metal products
2. Patents: 5 National Invention Patents, over 40 utility new model patents
3. Certifications: ISO 9001: 2008, ISO 14001: 2004
Production Capability
Internal gears, external gears and internal splines:
1. milled
2. shaped
3. ground
4. hobbed
Processing Capability
Our machine tools are able to manufacture gear and spline products with the following specifications:
Inspection Capability
To ensure that our products always meet or exceed customers’ quality requirements, New Yinye always focus on the details of the quality process control.
1. customized service based on requirements
2. design and development service
3. provide high quality products
4. accept small or mix orders
Please feel free to send us your requirements, we will be more than pleased to discuss any customers’ needs.
