Home > Products > TIG welding machine > Single Phase Portable Arc Welding Machin(ARC 250)
Single Phase Portable Arc Welding Machin(ARC 250)
US$ 66.5 - 130
/ Piece
20 Pieces(Min. Order)
- Ningbo/Shanghai and so on
- T/T Credit Card
You May Like
-
CE Approval Portable Arc Electric Welder ZX7-250
-
MMA Series Portable DC Inverter Welder ZX7-250
-
Stick Welder ZX7-250 Arc Inverter Welding Machine
-
Portable Mini DC Mma Welding Machine With CE--IGBT Inverter Welder
-
Welding Machine Accessores Earth Clamp Electrode Holder
-
Heavy Duty Portable Compact ARC180 Arc Electronic Invertor Welder for 4mm Electrode Steady Welding
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | SONSCN | Model Number | ARC250P | |
| Arc Current | 30-250A | Pulse Frequency | 50HZ | |
| Pilot Arc Current | 16A | Rated Duty Cycle | 60@160A,35@200A | |
| Motor Type | DC Motor | Dimensions | 31x13x20cm | |
| Usage | Manual Metal arc welding | Voltage | 220V | |
| Power(W) | 6.6KW | Certification | CE | |
| Warranty | 1 year | After-sales Service Provided | Overseas service center available |
Product Description
single phase portable arc welding machine(ARC 250)
Specification:
| Model | ARC250 | Input voltage | 50/60hz |
| 220V(1 phase) | |||
| Rated input current | Max.42A | No-load voltage | 80V |
| Efficiency | 85% | Input power | Max.6.6kw |
| Current range | 30-250A | Duty cycle | 60% |
| Suitable board | 1.5-13mm | Welding rod | 1.5-5mm |
| Weight | 4.7kg | Dimensions | 31x13x20cm |
| Trademark | SONSCN/ OEM | Protection class | IP21 |
| Standard | CE |
Product pictures
ARC-250 MMA portable IGBT inverter electronic welder
has the following characteristics:
1.Adopt with advanced PWM and IGBT inverter technique.
2.High efficiency,energy saving,light,portable,stable arc,good welding pool,high no-load voltage,good capacity of force compensation.
3.smooth arc ,small spatter.
4.Used in wide area, field operation , inside and outside decoration,etc.
5.Compared with the same products of home and abroad,it is compact in volume,light in weight,easy to install and operate.
6. Stable performance after continuous welding working,it can balance automatic when the voltage is waving, auto-protection of over-voltage, over current, over-heat, safe.
