Dual Network Burglar Alarm System Full Compatible With Contact ID

Specifications

Dual network burglar alarm system full compatible with contact ID

Name: PSTN and GSM Dual Network Alarm System

Model: SSG-GSM/TEL-8/16

Attestation: CCC,CE,ROHS

Type: GSM+PSTN Alarm

Description:

1.LED display, with keypad on the panel

2. Anti-tampering function:When the main control panel is removed or shaken from the wall, it will emit a high decible voice alert and auto dial the preset phone numbers at the same times.

3. Learning code: It can work with different sensors and the user can easily add and remove the sensors

4. Compatible with wired and wireless sensors: The panel has 99 wireless zones, 8/16 wired zones. It can use with sensors like PIR Motion Sensor, IR Beams, Smoke Detector, Gas Detector, Panic Buttons and so on.

5. The system can use with External Siren, no build-in siren

6. Great user-friendly design , easy for wiring

7. Low-power alert Function: Once the backup lithium battery is in low power state or AC power has been cut, the panel will send SMS to alert the user. If the system was use with Central Monitoring Station, the panel will also send this message to the Central Monitoring Station

8. Voice Instruction: The panel has voice instruction all the way when the user are remote control the system on phone. When alarm, the panel will alert which sensor, including Door Contacts, PIR Motion Sensors, Smoke Detector, Gas Detector and Panic Button, was triggered through voice instruction . And when you operate the system on the panel, there is no voice instruction.

9. Remote control:If the system do not alarm, the user can remote control the system to arm/disarm on phone after inputing correct password. And he can also send SMS to remote control the system to arm/disarm.When alarm, the system will send SMS to user first, then send message to Central Monitoring Station, After that, the system will auto dial the preset phone numbers. Once the alarm phone has been connected, the system will alert the alarm to user, what¡äs more, the user can also remote control the system to arm/disarm on phone at that time

10. Back-up battery: When the AC power is cut, the system can continue to work because it will turn on the backup battery automatically. And when the backup battery lack of power, the panel will charge for it.

11. Central Alarm Monitoring feature: SSG platform support zone voice alert. If PSTN and GSM works properly , alarm message will be sent to platform by PSTN, if PSTN fails , alarm message will be sent to platform by GSM automaticaly , if GSM fails or GSM signal be shielded,alarm message will also be sent to platform by PSTN.

12. Great lighting protection design

13. Great customized design

14.Private alarm monitoring: Alarm monitoring without central plarform(That means the user set the number by himself and the alarm message will be handled by his friends or neighbour ) . The way to send alarm message is the same to feature 11

15. GSM Network Alarm System: The system support SMS. And when the panel receive the SMS from the user, it will reply SMS to user automatically. In addition, the user can arm/disarm by SMS

16. we use high-quality,professional,industrial GSM module to disign and make our products.

17. Listen-in Function: After input correct password, the owner can hear the spot voice clearly. And the user can remotely prolong or cut listen-in on phone. What¡äs more the user can disarm the system during listen in.

18. On the remote controller, the user can arm/disarm the system and do emergency calling. It is very convinient for the user.

19.?The panel has wired siren connection port and the user can set sound/mute Alarm for the system

20. Inteilligient control system to check that whether the user has handled and confirmed the alarm. After confirmed, the system will not dial the pone numbers.

21. DC/AC power auto switch: charging by AC power , switch to DC power if AC power cut to make system no fail. the whole system can be used to prevented against burglar,robber,fire,etc.

22. The system can use with the electronic board to indicate the arm/disarm/alarm state to deterrent the intruder

23. The system is compatible with SSG Wireless Doorway Keypad.

24. The System can use with SSG Central Monitoring Station

We can use heart beat inspection to send message to central monitoring station. The time interval of the Heart Beat Inspection can be set by the user (the heart beat inspection is a kind of self-checking function that the terminal panel and the central monitoring station will have a "handshake" in a regular time to ensure that the system was in normal working state.). The user can set 6 groups of tie-in phone numbers in the panel, so the panel can automatically recogonise the dial in numbers, then tie-in phone can arm/disarm on phone without charge. While when there is a GPRS Network fautlt, the system will automatically turn on GSM Voice and SMS Alarm.

Parameter:

Main Product Parameter for GSM Alarm Panel

1. The Dimension of the Metal Shell: 27*26.6*8CM

2. Power Adaptor: AC To DV conventor.Input: AC 220( AC 110V/240V is optional,output:9VDC500mA.

3. Standby Current: ≤40mA, Alarm State Current: ≤350mA

4. Working Condition: Indoor, temperature: -10 ~ 50 degree, Relative humidity:≤90% atmospheric pressure: 86 ~106Kpa

5. Alarm Receiving Mode: AM. AM Receiving Distance:≥120M (In the open area)

6. Voice Instruction: The panel has voice instruction all the way when the user are remote control the system on phone. When alarm, the panel will alert which sensor, including Door Contacts, PIR Motion Sensors, Smoke Detector, Gas Detector and Panic Button, was triggered through voice instruction . And when you operate the system on the panel, there is no voice instruction.

7. Preset Phone Numbers: 6 Group (Maximum 30 digits for each group)

8. SMS Number: 1 Group

9. External Siren: ≥110dB; no built-in Siren

10. Frequency:315MHz/433MHz.

11. Protocol for CMS:GPRS

12. GSM Band:Triple-band 900/1800/1900 MHZ,Quad-band 850/900/1800/1900 MHZ

 Parameter:

1. The Dimension of the Metal Shell: 27*26.6*8CM

2. Power Adaptor: AC To DV conventor.Input: AC 220( AC 110V/240V is optional, output:9VDC500mA.

3.Standby Current: ≤20mA, Alarm State Current: ≤200mA

4. Working Condition: Indoor, temperature: -10 ~ 50 degree, Relative humidity;≤90% atmospheric pressure: 86 ~106Kpa

5. Alarm Receiving Mode: AM AM Receiving Distance:≥120M (In the open area)

6. Voice Instruction: The panel has voice instruction all the way when the user are remote control the system on phone. When alarm, the panel will alert which sensor, including Door Contacts, PIR Motion Sensors, Smoke Detector, Gas Detector and Panic Button, was triggered through voice instruction . And when you operate the system on the panel, there is no voice instruction.

7. Preset Phone Numbers: 6 Group (Maximum 30 digits for each group)

8. External Siren: ≥110dB,no built-in Siren

9. Frequency: 315MHz/433MHz.

10. Dual voice frequency dialing with single frequency current:

circle current 80mA 35mA 18mA ,

high frequency -7dBM+3dB-7dBM-5dB -7dBM+-3dB -7dBM+5dB-7dBM3dB ,

low frequency -9dBM+3dB-9dBM-5dB -9dBM+-3dB -9dBM+5dB-9dBM-3dB8 ,

high-low frequency gap: 2+-1dB ,frequency gap: <+-1.5%

11. Protocol for CMS:Contact ID
