AC220V CO and natural gas detector

Specifications

Home Gas Detector
1.High sensitivity
2.Full compatible with SSG control panel
3.CE,FCC approved

AC220V CO and natural gas detector





Wehave beenimitated,never to besurpassed!





SSG is the leading provider of CCTV and Alarm equipments and solution in Shenzhen China.





Main features:

• wired gas detector and wireless gas detector for choice
• High reliability sensor
• Auto-reset after alarm
• MCU processing adopted
• Malfunction auto-check indicator
• Alarm output N.C./ N.O. optional
• Dual sensor design
• Be able to work with electrovalve /exhaust fan
• SMT adopted, excellent stability
• Available for Natural gas, LPG, CO

TECHNICAL  SPECIFICATION:

• Operating voltage:  220V AC or 12V DC
• Rated power: ≤3W (220V AC power supply)
• Warm-up time: 3-5 minutes
• Alarm level: 10% LEL of Natural gas, 100 PPM of CO
• Alarm indicator:  Corresponding Red LED flash
• Malfunction indicator: Yellow LED on & Beeper long-buzz
• Alarm sound: ≥70dB (within 1 meter)
• Operating temperature: -10 to 50
• Environmental humidity: ≤95% RH (No congelation)
• Installation mode: Wall mounted
• Alarm output: Relay output /sound & flash alarm
• Dimension: 115*72*41mm
• Execute criterion: GB15322.2-2003



Home Gas Detector is a electric device which detects the presence of various gases within an area, usually as part of a safety system. This type of equipment is used to detect a gas leak and interface with a control system so a process can be automatically shut down. A gas detector can also sound an alarm to operators in the area where the leak is occurring, giving them the opportunity to leave the area. This type of device is important because there are many gases that can be harmful to organic life, such as humans or animals.





The Gas detector is full compatible with SSG central control panel
