Small Size Duplexer 50W 3 Cavity Duplexer for for Radio Repeater

Name: Small Size Duplexer 50W 3 Cavity Duplexer for for Radio Repeater
Brand: XUNLUN
SKU: 130691243
Availability: InStock

Shenzhen Xinlun Communication Technology Co., Ltd.

US$ 55 - 80 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

XUNLUN

Model Number:

SGQ-450S

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen Hong Kong Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name XUNLUN

Model Number SGQ-450S

Product Description

SPECIFICATIONS FOR DUPLEXER
Type	SGQ-150	SGQ-230	SGQ-350	SGQ-350D	SGQ-450	SGQ-450S(NEW)
Frequency(MHz)	136-172	220-240	336-370	336-370	380-470	380-470
Bandwidth(KHz)	±200	±500	±500	±500	±500	±500
VSWR	<1.5	<1.5	<1.5	<1.5	<1.5	<1.5
Insertion Loss(db)	≤1.2	≤1.2	≤1.2	≤1.2	≤1.2	≤1.2
Transmit receive separation(MHz)	5.7	7	10	10	10	10
Isolation(db)	>75	>75	>75	>75	>75	>75
Maximum Input power (W)	30	30	30	50	30	50
Connector	N-F/BNC-F	N-F/BNC-F	N-F/BNC-F	N-F/BNC-F	N-F/BNC-F	N-F/BNC-F
Nominal impedance	50Ω	50Ω	50Ω	50Ω	50Ω	50Ω
Dimensions(mm)	22015431	21415431	27515431	27019037	22815431	2257762
Weight(kg)	1.2	0.9	1.2	1.8	1.1	1.1

Our Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

* Training how to instal the products, training how to use the products.

* Engineers available to service overseas.

Packing & Delivery

Packaging
Size	28 (L) 22(W) 75 (H)cm
Weight	10.75kgs
Packaging Details	10PCS as one carton We adopt good quality shock proof foam and bubble bag to protect products well.

Packaging
Size	28 (L) 22(W) 75 (H)cm
Weight	10.75kgs
Packaging Details	10PCS as one carton We adopt good quality shock proof foam and bubble bag to protect products well.
