HV-800 Electric Armature Vertical Flexible Rotor Balancing Machine From China Supplier

Name: HV-800 Electric Armature Vertical Flexible Rotor Balancing Machine From China Supplier
Brand: Beacon
SKU: 130668017

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Beacon

Model Number:

HV-800

Taian Beacon Machine Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Beacon

Model Number HV-800

Power Electronic

Usage Auto Testing Machine

Product Description

HV-800 electric armature vertical flexible rotor balancing machine from China supplier

the machine fits for balancing adjustment for parts with disc shape such as fan,pressure plate,flywheel, brake disc,

ring blower, impeller, arrester, saw blade, pulley. Adopt industrial computer (SCM) in measuring system.

Digital displays for rotate speed, measured value and phase, and unbalanced amount shows in “g” directly.

The system can correctly display the unbalance amount (“g”) of workpiece and its phase and also can display its memory

after you input various parameters through the keyboard according to the geometric dimension of different kinds of workpiece.

Simple operation, straight display Adopt electromagnetic sensor in electromechanical transducer,. Feature in large output,

reliable performance and excellent stability.

Model	HV-5	HV-20	HV-50	HV-100	HV-200	HV-400	HV-800
Working piece quantity range:kg	0.1-5	0.5-20	3-50	5-100	10-200	30-400	30-800
Working piece diameter:mm	Φ500	Φ500	Φ500	Φ800	Φ800	Φ800	Φ1200
Balancing speed:r/min	250-1500	250-1500	250-1500	250-1500	250-1500	250-1500	250-1500
Min. achievable residual unbalance:gmm/kg	≤3	≤3	≤3	≤3	≤3	≤3	≤3
Unbalance reduction rate%	≥90	≥90	≥90	≥90	≥90	≥90	≥90
Driver power:KW	0.37	1.1	1.5	4	4	5.5	7.5
speed adjustment mode:	Frequency	Frequency	Frequency	Frequency	Frequency	Frequency	Frequency
