Batching Scale Weighing Control Instrument

Batching Scale Weighing Control Instrument photo-1
US$ 300 - 400 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
MANYYEAR
Model Number:
MEP500A10
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port of China
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name MANYYEAR
Model Number MEP500A10
Type Other, BATCHING SCALE
Power Supply 220VAC/24VDC
Display Type LED
Rated Load 999999
Accuracy 0.001
Product Description
MEP 500A10  Batching scale weighing control instrument

Features

This product is suitable for building materials, chemical, food, steel, feed and other industries.

Congregating weighing, display, communication and control in one.

Providing increase and reduction function selection.

Switching power, Voltage range: AC 185--265V

With Analog and digital dual filtering function.

Automatic error diagnosis, easy to determine the fault.

Ingredients manual / automatic switching function.

Batching process at any time to pause, pause, cancel and continue Ingredients.

Automatic zero tracking function  Power auto-zero function.

Batching start auto-zero function.

Maxmum 6 kinds ingredients can be controlled.

All material has a compensation function and the result of counting can be printed.

Support adjusting at any time to modify recipes.

Automatic accumulated material consumption.  With automatic collision momentum and delay function.

Manual/automatic gap setting and revising function.

Password Authoration function.

Zero, Tare, Over load, Tolerance range and Filtering strength can be setted.  Date, time display and setting function.

Technology

Interior resolution ratio
less 10000000
Power supply
 AC220V(AC175V-285V),50HZ/60HZ
Product capacity
less 10W
Working ambient degree
-10°C~40°C
Nolinear error
less 0.00015%FS
Working ambient humidity
less 90%Relative humidity (without condensation of water)
 A/D conversion speed
200Times/sec
Input sensitivity
less 1.8uV
Sensor exaction voltage
DC5V,200mA,Can be parallel four 350 Ω sensors
Sensor port input impedance
more than 20MΩ
Sensor zero voltage range
 -10mV~10mV
 Display window
128 * 84 LCD Chinese display
Print interface
communication distance of RS232: 15m baud rate for 9600, parity check
Weighing sensor types
resistance strain type weighing sensor
Weight Unit
g, kg, t
The highest Display Accuracy
1 /15000
Switch pointed Capacity
shock capacity AC220, 3A or 24V/500mA
Control contact capacity
AC200V/5A or 24V/500mA
Packaging & Shipping

Product photo

batching scale weighing control instrument



Packing picture

batching scale weighing control instrument

Our Services

24Hr for response time.

5-7days for sample time.

15-25days for delivery time.

12 months for quality assurance time.

ODM, OEM support
