Mutil functions balancing machine YYW-300A static and dynamic balancing
Product Description
Features:Hard backing horizontal dynamic balancing machine;
Using the wheel backing, universal coupling to drive;
YYW-300A Universal Joint Drive Balancing Machine Varibal frequency control motor;
Industrial control computer data processing, color screen real-time shows amount and angle of unbalance, and rotation speed;
Bed is overall foundry with good stability;
Balance and measure on single side, double side
More Features:
Single side YYW-300A Universal Joint Drive Balancing Machine is hard supporting horizontal dynamic balance machine, with roller bearing, universal couplings drive,
regular for double speed motor drive, "A" type for frequency conversion motor speed and frequency converter,
the industrial control computer for data processing,
color screen real-time display don’t balance phase Angle and value,
real-time speed, lathe bed all use whole casting, the stability is good.
Widely used in electric motors, blower, diesel engine, agricultural machinery, textile machinery, and other industries,
can be in the single side, double side and multiple correction plane balance measurement, suitable for axle,
dish out and center of gravity of the rotor. Have high efficiency, precision accurate, show intuitional, reliable quality,
easy maintenance, the characteristics of software with ordinary workpiece and standard rotor two calibration function,
overcoming the other hard supporting balance machine measurement system to users to calibration equipment defects,
and the coupling compensation function and so on many kinds of measuring method and function to choose,
can realize the input parameters, preview, the experiment, the results storage, print, operating all adopt the localization menu structure, the man-machine dialogue, automatic hints..
Technical data :
TechaTechnical data at a glance | YYW-300A |
Mass scope of workpiece kg | 10-300 |
Biggest diameter workpiece mm | 1200 |
Two span of supports mm | 60-1700 |
Trunnion support mm | 10-90(90-180 option) |
Balancing speed r/min | 300-2500 |
Min achievable residual unbalance amount | ≤1gmm/kg |
Unbalance reduction ratio % | ≥90% |
Motor power | 5.5Kw |
mode of speed regulation | Variable frequency speed regulation |
Transmission model | Universal joint |
our factory anmd team
Our service
welcome you to visit to our factory ,and show you how to operate for free
One year warranty for parts , Lifetime technical support
If you become our old customers , will give you lowest price
