Carbon Steel T Nut
Carbon Steel T Nut
T nut with 4 Prongs (mm) | ||||
Metric Size |
Thread |
A |
B |
C |
M4*0.7 |
15 |
5.5 |
6-8 |
|
M5*0.8 |
15 |
6.2 |
8-12 |
|
M6*1.0 |
17.6 |
8 |
10 |
|
M8*1.25 |
22 |
9.3 |
10 |
|
M10*1.5 |
25 |
11.2 |
10-30 |
|
Inch Size |
1/4*20 |
17.6 |
8.2 |
12-20 |
5/16*18 |
22 |
9.3 |
10 |
|
•The figure above shows the regular size of Dongguan Kaiyang's
T nut with 4 Prongs.
• We also welcome buyers to send us your design sketch. It will work better to confirm the design first before you buy it.
Dongguan Kaiyang T nut with 4 Prongs | |
Price |
0.006-0.3 (USD) |
Min.Order Quantity |
1000 Piece/Pieces |
Supply Ability |
100 tons per month |
Material |
Carbon Steel |
Finished |
Zinc Plated, Yellow Zinc Plated, Black Oxide |
Function |
1. A T-nut, T nut, or Tee Nut (also known as a blind nut,[1] which can however also refer to a rivet nut) is a type of nut used to fasten a wood, particle or composite materials workpiece, leaving a flush surface.
2. T Nut with 4 Prongs can locate automatically and lock tightly during assembly. It has a long, thin body and a flange at one end, resembling a T in profile. The flanges of T-nuts often have hooks or serrations on the prongs that dig into a wooden work piece as the bolt is tightened from the opposite side of the piece, providing better retention. 3. Our nut can apply to wood or plastic fruniture or for Climbing Holds. |
Packing Detail |
→ We strive for excellent customer service and fast shipping. The package of our products are available in plastic bag and woven pp bag.
Package : 5000-10000 EA /per bag. About 20-27kg (Weight of products may vary depending on the product specifications)
→ We have access to various kinds of fastener products. If you do not see it listed, just send us an email or leave message on this website. We will reply your questions as soon as possible. |
Delivery Detail |
If you seek for more details about our tee nut or having any questions, please do not hesitates to contact us. We will do our best to answer your questions. |
Q:Is Dongguan Kaiyang manufacture or trading company?
A:We are manufacturer with more than 20 years experience on cold forge nut and bolt and have professional QC and R&D teams to assure our quality. We also welcome you to visit our factory.
Q: How can I check the quality?
A: Dongguan Kaiyang can send you free samples for testing.
Q:What is your best price?
A:You could enjoy more favorable price with large quantity.
Q:How to order?
If you are satisfy with our products, please tell us which items, mesh, usage,quantity,ect you want to order.
We will make a performa invoice(PI) for your order to confirm and deliver the goods ASAP when your payment has been approved.
Q: What kinds of payment terms do you have?
A:We accept the payment by T/T and Paypal.
Q:What if I need a larger quantity?
A: Discount Apply with Large Quantity.
Contact with us for Surprice Price.
Factory Overview & Equipment List:
Equipment Name |
Type |
Quantity |
Nut Forming Machine |
41B |
1 |
Nut Forming Machine |
30B |
2 |
Nut Forming Machine |
24B |
3 |
Nut Forming Machine |
19B |
6 |
Nut Forming Machine |
17B |
5 |
Nut Forming Machine |
14B |
35 |
Nut Forming Machine |
11B |
8 |
Nut Forming Machine |
8B |
6 |
Auto Tapping Machine |
φ12-φ25 |
105 |
Auto Stamping Machine |
36 |
|
Flat die thread rolling Machine |
30A |
40 |
Flat die thread rolling Machine |
60A |
10 |
Three-die cylindrical rolling |
30 |
|
CNC(Computerized Numerical Control) |
3 |
|
Milling Machine |
4 |
|
Grinding Machine |
12 |
|
EDM(Electrical Discharge Machining) |
8 |
|
WEDM(Wire Electrical Discharge Machining) |
6 |
If you would like to know more information of our bolts and nuts, please click the product you are interested in to get further details, Thanks.
