China Top Quality Semi Automatic Double Head Packing Scale

China Top Quality Semi Automatic Double Head Packing Scale thumbnail-1
China Top Quality Semi Automatic Double Head Packing Scale thumbnail-2
China Top Quality Semi Automatic Double Head Packing Scale photo-1
China Top Quality Semi Automatic Double Head Packing Scale photo-2
US$ 13,000 - 13,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Chemical, Commodity, Food, Medical, Other, Chemical, Commodity, Food, Medical, Putty powder,Pesticide powder
Packaging Type:
Bags
Contact Supplier Request Quote Chat Now
Harbin Link Auto Technology Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Chemical, Commodity, Food, Medical, Other, Chemical, Commodity, Food, Medical, Putty powder,Pesticide powder
Packaging Type Bags
Packaging Material Plastic
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage 220V/380V
Power 8kw
Place of Origin Heilongjiang, China
Brand Name Hlink
Model Number HLKP25
Dimension(L*W*H) 4560MM*1700MM*3570MM
Weight 1500kg
Certification CE ISO SGS
After-sales Service Provided Engineers available to service machinery overseas
Packing Scale

Product Application

Packing for flour,bran,peanut,soy, peanut ,rice,powder,animal feed, fertilizer etc

Items
HLKP25
Packing weight
5-25kg
Measurement accuracy
+30g
Packing speed
>550bags/H(5kg)
Power
8kw
Material bag fold
304stainless steel
Height
3.4M
Conveyor length
4.1M
Air consumption
<2.5cubic meter
Name
Type
Brand name
Function
Single three phase breaker
C65N-D
Schneider
Short-circuit protection and overload protection
thermal relay
LR2-D…C
Schneider
Overload protection
Contactor
09M7C
Schneider
Breaker
C65N-D industrial
Schneider
DC switching power supply
S-35-24
Schneider
24V DC power supply
Relay
G6B-1174
Schneider
Driving electromagnetic valve
Intermediate relay
HH52P
Schneider
Level proximity switch
M30
Shanghai Qianwei
Material Level Detection
Photoelectric switch
M18
OMRON
Auto thread cutting
Folder bag limit switch
WLNJ
Schneider
bag folder input signal
Cylinder (folder bag)
MDB40*100
Japan SMC
Cylinder(up-down vibrate bag)
MDB63*150
Japan SMC
The electromagnetic valve(DC24V)
VFS2000 series and VFS3000series
Japan SMC
drive cylinder
Triples
AW30-03BG
Japan SMC
Japan SMC refueling, water treatment, regulator
Main machine bearing
screw and mix
German SKF
screw support and convey
Weighting meater
LINK-3.0
Hlink
AD change and Motion control
Touch screen
Schneider
To achieve packet packing, centralized control

Main Features

Semi automatic packing machine for different flour,grits,seed,like rice,wheat,peanut,soy,wheat flour, corn flour
Name
Model
Factory
Quantity
Programmable Controllers
DVP40ES211T
Delta Electronics
1
Programmable Controllers extend
DVP16XN211T
Delta Electronics
2
server Driver
ASD-0721AB
Delta Electronics
2
inverter
VFD007EL43A
Delta Electronics
2
Inverter
VFD015EL43A
Delta Electronics
2
Inductive proximity switches
XS2-18
Schneider
4
Magnetic switch
D-M9B
SMC
10
Level proximity switch
M30
Shanghai Langfu
4
Sewing photoelectric
G18
Qianwei
1
Touch screen
B07S411
Delta electronics
1
Touch screen
B07S415
Delta electronics
1

                                                                   Who we are?  Hlink ?

We are one professional team,and we are located in Harbin China,we have totally 228workers,workshop and office is more than 50 000square meters.
      Our aim is:To do China best packaging scales
                         To do China most advanced packaging scales
                         To do the perfect packing solution for our client
                         Offer best after sales service to our client
                         Our name is Harbin Link Auto Technology Development Co.,Ltd .(Hlink)
4th August 2003 : Three professors from Harbin Institute of Technology(HIT) made a very important decision that they

                                  have to set up a plant for packing scale,same day they registered the license from China

                                  government: Harbin Link Auto Technology Development Co.,Ltd .(Hlink)The three professors aim: to

                                  do China's best packaging scales

2003-2007: are the company developing years
15th March 2008 :After 5years running, Hlink grow bigger,and cover half of China market.

                                 To give good service to the Client. Hlink establish: Zhengzhou Branch Office
23th March 2009: ShanDong Liaocheng Aftersale service Office established
                                  Developed duplex packing machine
29th May 2010:Hlink developed material mixed meter,it make the mixing control system more easily,easy operate,can

                           connect with the computer realize remote control

8th Jun 2011: Hlink automatic packing machine working 12month no malfunction.

                          Hlink purchased most advanced AMADA CNC bending machines and balancing machines
31th Dec 2012: In this year Hlink had saled 1190sets packing machine
                          Hlink enlarge factory space 12 000Square meter
Dec 2013: Construction the new office and new building

31th Dec 2014:Hlink saled 2000sets packing machine
                            Hlink was rated as high-tech enterprises by Heilongjiang province

31th August 2015:Hlink get Utility model patent certificate for : Pasta/noodles packing machine
31th Dec 2015: Hlink the total amount of sales more than 20 000 000USD

Certifications
HLINK TEAM
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to install the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Packaging
Size
1300mm×1800mm×2100mm
Weight
860kg



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Other items

Within 7 working days after receive the payment

Install time:within 7days

Warranty Time:2years
