“Huatian”HT-SXX series of Double Planetary Power Mixer are new type high efficiency mixing equipment being researched and developed and improved independently by ourselves based on digestive absorption of advanced technology from home and abroad.
This series of equipment are widely used in industries of electronics, chemicals,foodstuff,medicines,building materials,agrochemicals etc. for mixing,reacting,dispersing,dissolving,homogenizing and emulsifying of solid-solid,solid-liquid,liquid-liquid materials like fluid of polymer lithium-ion battery,liquid lithium-ion battery fluid,electronic electrode paste, adhesive,molding adhesive,silicone adhesive,PU sealants,anaerobic adhesive,printing ink,pigments,cosmetics,ointment etc.
Technical Data:
Model |
HT-SXX2 |
HT-SXX15 |
HT-SXX25 |
HT-SXX60 |
HT-SXX100 |
HT-SXX200 |
HT-SXX300 |
HT-SXX500 |
HT-SXX1000 |
|
Volume |
2L |
15L |
25L |
60L |
100L |
200L |
300L |
500L |
1000L |
|
Tank Size(mm) |
DIAMETER 250*200 |
DIAMETER 300*300 |
DIAMETER 350*350 |
DIAMETER 450*500 |
DIAMETER 550*550 |
DIAMETER 750*600 |
DIAMETER 750*800 |
DIAMETER 1000*850 |
DIAMETER 1250*1000 |
|
Revolution Motor(kw) |
0.75 |
1.5 |
2.2 |
3 |
4 |
7.5 |
11 |
22 |
30 |
|
|
Revolution Speed(Variable Speed by Frequency Inverter)(RPM) |
0-60 |
0-60 |
0-60 |
0-60 |
0-60 |
0-40 |
0-40 |
0-35 |
0-35 |
|
Autorotational Speed(Variable Speed by Frequency Inverter)(RPM) |
0-70 |
0-70 |
0-70 |
0-70 |
0-70 |
0-60 |
0-60 |
0-45 |
0-45 |
|
Disperser Motor(kw) |
0.75 |
1.5 |
2.2 |
4 |
5.5 |
11 |
11 |
30 |
37 |
|
Dispersing Speed(Variable Speed by Frequency Inverter)(RPM) |
0-1500 |
0-1500 |
0-1500 |
0-1500 |
0-1500 |
0-1500 |
0-1500 |
0-1500 |
0-1500 |
|
Scraper Speed(Variable Speed by Frequency Inverter)(RPM) |
0-60 |
0-60 |
0-60 |
0-60 |
0-60 |
0-40 |
0-40 |
0-35 |
0-35 |
|
Vacuum Degree(MPa) |
-0.098 max. |
-0.098 max. |
-0.098 max. |
-0.098 max. |
-0.098 max. |
-0.098 max. |
-0.098 max. |
-0.098 max. |
-0.098 max. |
|
Lifting Stroke(mm) |
200 |
400 |
500 |
600 |
650 |
700 |
900 |
1000 |
1100 |
|
Weight(kg) |
250 |
800 |
1000 |
1750 |
2500 |
3000 |
3500 |
4500 |
6500 |
|
Outer Size |
L(mm) |
700 |
960 |
1150 |
1900 |
2500 |
2500 |
2640 |
2670 |
2900 |
W(mm) |
400 |
450 |
530 |
1000 |
1000 |
1000 |
1080 |
1100 |
1400 |
|
H(mm) |
1700 |
2000 |
2300 |
2400 |
2500 |
2500 |
2650 |
3600 |
3900 |
|
Lifting Mode |
Manual(2L),Pneumatic,Hydraulic |
|||||||||
In standard export wooden cases.
We accept both FOB term and CIF term.
Installation:
Usually the installation of equipment will be done by the customer themselves according to our detailed operation manual. We may also send our engineer(s) to facilitate our customer for the installation,correct operation of the equipment and staff training with expenses like return ticket,board and lodging to be borne by the customer.
Warranty:
We provide our customer with one year of guarantee starting from commissioning of equipment,but not exceeding three months after B/L date.
Trouble shooting:
We are 24 hours ready for answering customer’s queries about operation. Customer may give us a call,or send us an email or leave a message on SKYPE,QQ,Wechat,WhatsApp,Viber,we’ll give you our prompt reply.
Contact Info:
Contact Person: Weldon Tang
Tel/Fax: +86-532-68603193
Cell: +86-13969614377
Messenger:
SKYPE: weldontang88;
QQ: 1453231452;
Wechat: weixintang08
Viber;
Website: ; http://lzsyhj.en.china.cn
Laizhou Huatian Chemical Equipment Co.,Ltd. (herein after referred to as “Huatian”) is located in the beautiful and affluent bay city Laizhou with convenient land and sea transportation and its distance to both Qingdao port and Yantai port is about 180 kms. “Huatian” invests to set up its wholly-owned subsidiary company Qingdao Weltek International Trade Co.,Ltd. (herein after referred to as “Weltek”) in the port city of Qingdao in March of 2016,which is fully in charge of the export business of “Huatian”equipment. Meanwhile “Weltek” also professionally exports Titanium Dioxide and related products which are widely used for production of paints,coatings,printing ink,plastic color master batch,plastic products,decor paper,rubber products and synthetic fibre etc.
The following are the company profile of “Huatian”:
“Huatian” devotes itself to R & D,design,manufacture,marketing and service of fluid and semi-fluid equipment and can look back on production experience for more than two decades. “Huatian” equipment enjoys excellent reputation and sells well nationwide in China and has been exported to more than 20 countries in the world. Innovations and continuous development have made “Huatian” industry-leading. The main equipment covers kettles and tanks,kneaders,mixer series,disperser series,emulsifying and grinding equipment series,stone-like paint equipment,dry-mixed mortar equipment and paint complete equipment which are widely used in industries of chemicals,plastics,foodstuff,pharmaceutical,paper making,leather chemical etc. and are mainly used for the production of paints,coatings,printing inks,stone-like paints,adhesives,sealants etc. “Huatian” also provides customers with non-standard production line designing scheme and whole factory output turn-key project according to actual technological process and production technology. “Huatian” equipment has excellent performance and superior quality with independent intellectual property rights and with a dozen state owned invention patents obtained. Part of equipment has passed CE certification.
“Huatian” always adheres to the principle of mutual benefit and win-win in the trade with customers both at home and abroad over the years and endeavors to make “Huatian” into an equipment supplier to be highly competitive and industry-leading.
“Huatian” all the way follows the principles of “to survive by quality,to perfect by strictness,to have trust by integrity”. We’ll strive to develop and generalize advanced and high efficient new equipment,so as to improve production efficiency and create profit maximization for customers.
