Home > Products > Emulsifying and Grinding Series > Horizontal Pipeline Emulsifying Machine/High Quality High Temperature Emulsifying Machine
Horizontal Pipeline Emulsifying Machine/High Quality High Temperature Emulsifying Machine
- QINGDAO
- T/T
You May Like
-
Colloid Mill/Material Grinding Processor
-
Horizontal Pipeline Emulsifying Machine for Cosmetics Emulsion
-
Colloid Grinder Colloid Mill
-
Horizontal Pipeline Emulsifying Machine
-
Pipelined Emulsifying Machine,Horizontal Type Emulsifying Machine
-
Stainless Steel Colloid Mill/chilli Powder Filling Machine Food Grade Sanitary Grinding Machine
Product Details
| Condition | New | Mixer Type | Homogenizer | |
| Product Type | Paint | Application | Viscous Fluid | |
| Additional Capabilities | Milling | Place of Origin | Shandong, China | |
| Brand Name | HT | Model Number | HT-RHJ | |
| Max. Loading Capacity | 1100L | Voltage | 380V(Designed as diffevent countvies) | |
| Power(W) | 0.3KW~75KW | Dimension(L*W*H) | Custom Made | |
| Certification | ISO | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
“Huatian”HT-RHJ series of Horizontal Pipeline Emulsifying Machines are widely used for any material that needs to be mixed,homogenized,pulverized,suspended and dissolved,like coatings,cosmetics emulsion and gel etc. The materials from incompatible solid phase,liquid phase and gaseous phase are instantly dispersed and emulsified evenly and subtly under combined action of mature technology and moderate additives. Finally stable and high quality product is achieved through the high frequency moves in circles.
Model | HT-RHJ100 | HT-RHJ101 | HT-RHJ105 | HT-RHJ110 | HT-RHJ125 | HT-RHJ130 | HT-RHJ150 | HT-RHJ175 | HT-RHJ1100 |
Power(kw) | 0.30 | 1.1 | 4 | 7.5 | 18.5 | 22 | 37 | 55 | 75 |
Rotate Speed (RPM) | 0~1000 | 2880 | 2880 | 2880 | 1440 | 1440 | 1440 | 1440 | 1440 |
A | 35 | 89 | 102 | 114 | 178 | 228 | 279 | 318 | 330 |
B | 64 | 152 | 165 | 190 | 254 | 295 | 356 | 394 | 432 |
C | 279 | 622 | 838 | 1130 | 1283 | 1372 | 1638 | 1994 | 2599 |
D | ~ | 889 | 1168 | 1575 | 1854 | 2108 | 2362 | 2794 | 3516 |
E | ~ | 200 | 250 | 300 | 356 | 356 | 356 | 559 | 559 |
Volume(L) | 1.1~10 | 15~100 | 50~200 | 90~1000 | 150~2000 | 200~3000 | 800~5000 | 1500~8000 | 1500~20000 |
Weight(kg) | 16 | 41 | 73 | 168 | 300 | 523 | 614 | 818 | 955 |
Major advantages
The series of Horizontal Pipeline Emulsifying Machines developed by us have the following advantages:
1)It is well-adapted to different materials like large granules or high viscosity materials.
2)Temperature resistance: It is suitable for high shearing and homogenizing to materials with temperature range from minus 40 degrees to 200 degrees centigrade above zero.
3) Good shearing and emulsifying effect: Can be used for production of micro-emulsion and superfine suspension liquid.Due to simultaneous working of three groups of dispersion head (stator+rotor) in the working chamber,the mixed liquid produced after high shearing has better stability.
Usually Package By Three Plywood,Suitable And Convenient For Shipment
Warranty:
Equipment warranty for one year. As customers confirm that they received the goods, we will provide free replacement parts for damaged parts (in addition to the damage caused by incorrect operation), we will be available through federal, air, sea.
Electrical Engineering:
Lifetime maintenance, Huatian provide Chinese operating manual instructions on how to install and maintain. If the customer has any technical problems, we will provide guidance by phone, e-mail and other means.
Installation:
The overall complexity of the installation of the machine we have for you, or custom equipment or complete production lines. After installation, we will check the machine, operation of equipment, installation and provide you with a test report.
Train
Our clients can operate according to the instructions. Or before delivery, customers can come to our factory, our engineers can guide training how to operate and maintain the equipment in the field.
Welcome domestic and foreign agents.
1,Laizhou Huatian Chemical Equipment Co.,Ltd. specializes in the research and development,design,manufacture,marketing and service of fluid and semifluid equipment. The main equipment covers kneaders,intelligent integration of complete sets of equipment for production of coating,emulsion paint and stone-like coating,reaction kettles,mixing machines,emulsifying and grinding equipment etc.,which are widely used in industries of petroleum,chemicals,plastics,foodstuff,pharmaceutical,paper making,leather chemical and many other such industries. We can also provide users with non-standard production line designing scheme and whole factory output turn-key project according to actual technological process and production technology. Our equipment has excellent performance and superior quality with independent intellectual property rights and with a dozen state owned patents applied for.
2,Our equipment sells well all over China and has been exported to countries in Central Asia and Iran,India,Vietnam,Brazil etc. since long ago.
3,Our company always adheres to the principle of mutual benefit and win-win in the trade with customers both at home and abroad over the years and endeavors to make ourselves into an enterprise to be highly competitive and industry-leading.
4,The company follows the principles of “To survive by quality,to perfect by strictness,to have trust by integrity” and will sincerely cooperate with you through high standard equipment and fast and efficient service to create a better future together.
About Delivery time
Q-----What’s the delivery term for making business with us?
A--Usually we send the shipment in FOB term.However, the terms of CIF are acceptable which depend on the preference of clients.
About Lead Time
Q------What’s the lead time after placing the order?
A------Usually it takes about 15~30 days after we received your confirmation.
However, it would depend on our production line schedule(the timing clients place order)and the complication of the item.
About Payment Term
Q------What’s the Payment Term?
A------By T/T in Advance, or Irrevocable L/C as Sight.
