Place of Origin
Jiangxi, China
Brand Name
JCTT
Model Number
XHX40.146J.001/XHX40.171J.01/XHX40.181J.01
Gearing Arrangement
Spur
Output Torque
73.6 Nm
Rated Power
40HP
Input Speed
540rpm
Output Speed
ratios 1.46:1,1.71:1,1.81:1
Specifications
1. 40HP;Output torque 73.6 Nm2. High quality, low noise;
3. High unversality, simple structure
4. Mature techniques;
This series gearbox is mainly used on Rotovator (rotary cultivator).
It has characteristics of high univerality, simple structure and good performance.
It is one of JCTT's mature product. Mainly exported to Europe & America.
| Code | Power (HP) | Gear Ratio (i) | Input Speed (r.p.m.) | Weight (kg) |
| XHX40.146J.01 | 40HP | 1.46:1 | 540 | 44 |
| XHX40.171J.01 | 40HP | 1.71:1 | 540 | 44 |
| XHX40.181J.01 | 40HP | 1.81:1 | 540 | 44 |
| XH50A.001-1500 | 50HP | 1.69:1 | 540 | 44 |
| XH50A.002-1500 | 1.69:1 | 540 | 44 |
