Home > Industrial Equipment & Components > Power Transmission Parts > Gearbox > Baler Transmission Gearbox
US$ 65 - 3,000
MOQ: 2 Sets
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Brand Name:
JCTT
Model Number:
XH100.583J.00
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai etc.
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangxi, China
Brand Name
JCTT
Model Number
XH100.583J.00
Gearing Arrangement
Spur
Output Torque
Lev 1:965.08 Nm / Lev 2: 4825.38
Rated Power
60HP
Input Speed
500 r.p.m
Output Speed
Ratio 5.83:1
Baler Transmission Gearbox
A new type developed based on the operation features of bundle machine .With its characteristics of simple structure,stable quality ,strong serviceability as well as wide application ,it is exported and unanimously approved by the users .It has acquired National Patent for Utility Model.
| Code | Input Power (HP) | Input Speed (r.p.m) | Input Torque (Nm) | Level I Gear Ratio (i) | Level I Output Torque(Nm) | Level I Output Speed(r.p.m.) | Levl II Gear Ratio(i) | Level II Output Torque(Nm) | Level II Output Speed(r.p.m.) | Weight (Kg) | Outline Dimension (mm) |
| XH100 | 36.75 | 500 | 702 | 1.38 | 965.08 | 363.64 | 6.88 | 4825.38 | 72.73 | 114 | 700x440x360 |
| XH101 | 36.75 | 500 | 702 | 1.17 | 818.85 | 428.57 | 5.83 | 4094.26 | 85.71 | 114 | 700x440x360 |
